| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2134 x 1118 x 750 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Umbrella hole diameter | 57 mm | |
| Center recessed tray compartment dimensions | 610 x 406 x 38 mm | |
| Apron height below tabletop | 127 mm | |
| Leg span lengthwise | 1829 mm | |
| Leg span widthwise | 813 mm | |
| Knee clearance height under apron | 623 mm | |
| Corner radius | 50 mm | |
| Edge trim width | 25 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 35 kg | |
|---|---|---|
| Distributed tabletop static load | 136 kg | |
| Center point load capacity | 45 kg | |
| Seating capacity | 6 persons | |
| Powder coating thickness | 80 um | |
| Recommended cover weight capacity | 23 kg | |
| Frame rust resistance lifespan | 5 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop frame and lattice | Sand-cast aluminum alloy | |
|---|---|---|
| Surface finish | Multi-step antique bronze powder coat | |
| Apron assembly | Cast aluminum with scroll openwork | |
| Support legs and base crossbars | Thick-walled cast aluminum tubing | |
| Center recessed tray insert | Black matte food-grade plastic liner | |
| Umbrella hole cap | Matching cast bronze aluminum plug | |
| Assembly fasteners | Stainless steel 8mm hex bolts | |
| Foot pads | Non-marking rubber caps | |
| Surface texture | Hammered embossed cast texture | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Umbrella hole function | Accepts standard patio umbrellas up to 57mm pole diameter | |
|---|---|---|
| Center inset compartment | Functions as ice bucket or serving tray with removable liner | |
| Surface drainage | Open lattice tabletop design allows rainwater to drain freely | |
| Assembly requirement | Knock-down assembly with included hardware and hex key | |
| Weather performance | Withstands full sun, rain and humidity exposure without rusting | |
| Seating access | Uniform 711mm edge clearance per seat position | |
| Leveling capability | Adjustable rubber foot pads compensate for uneven patio surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Packaging note | Engineering, not supplier-measured data | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio application | Suitable for backyard, garden or covered porch dining areas | |
|---|---|---|
| Commercial outdoor use | Applicable for restaurant sidewalk patios and cafe outdoor seating | |
| Climate suitability | Performs well in coastal, rainy and high-humidity environments | |
| Recommended pairing | Pairs with 6 cast aluminum patio armchairs with weatherproof cushions | |
| Surface compatibility | Safe for stone paver, concrete, wood deck and tile patio surfaces | |
| Maintenance requirement | Wipe clean with damp cloth; use fitted cover when not in use | |
| Use function | Supports casual dining, tea service and small outdoor gatherings |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating and table safety general requirements reference for procurement | |
|---|---|---|
| EN 581-3:2017 | Outdoor table mechanical safety and structural performance test criteria reference |
Standards applicable to China-market projects
| GB/T 24821-2009 | Outdoor furniture metal table mechanical performance test reference for load and stability |
|---|
This product must meet the following technical requirements: 1. GB/T 24821-2009: Outdoor furniture metal table mechanical performance test reference for load and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
