Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1850 x 1070 x 750 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Leg section dimension | 60 x 60 mm | |
| Under-table knee clearance height | 670 mm | |
| Lower stretcher height from floor | 150 mm | |
| Tabletop border width | 80 mm | |
| Center umbrella hole diameter | 50 mm | |
| Adjustable foot height adjustment | 10 mm | |
| Long-side seating space per person | 615 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Table static distributed load capacity | 136 kg | |
|---|---|---|
| Table net weight | 32 kg | |
| Seating capacity | 6 people | |
| Powder coat finish salt spray resistance | 500 hours | |
| UV resistance rating for finish | Grade 4 | |
| Ceramic tile surface abrasion resistance | PEI Class 4 | |
| Frame wall thickness | 3 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame | Cast aluminum with bronze powder-coat finish | |
|---|---|---|
| Tabletop field tiles | Ceramic tile laid in herringbone pattern | |
| Tabletop border tiles | Contrasting medium brown ceramic tile inlay | |
| Table base stretcher | Cast lattice-pattern metal matching frame | |
| Leg feet | Nylon adjustable leveling glides | |
| Tabletop substrate | Weather-resistant fiber cement backer board | |
| Fasteners | Stainless steel 304 grade hardware | |
| Finish topcoat | UV-stabilized matte clear sealer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Center umbrella hole | 50mm diameter through table center, accepts standard patio umbrella pole | |
|---|---|---|
| Leveling adjustment | Threaded nylon feet adjust up to 10mm to stabilize on uneven surfaces | |
| Weather performance | All-weather construction resists rain, UV exposure, and rust | |
| Assembly requirement | Knock-down leg attachment with included hardware | |
| Surface maintenance | Non-porous tile top wipes clean with mild detergent, no sealing required | |
| Structural bracing | Full perimeter lower metal stretcher prevents leg racking during use | |
| Seating compatibility | 750mm height pairs with standard 450mm seat height patio dining chairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyard wood or composite deck dining areas | |
|---|---|---|
| Garden courtyard installation | Pairs with cast aluminum seating for formal exterior entertaining | |
| Poolside dining areas | Corrosion-resistant materials resist chlorinated water splash and humidity | |
| Commercial café outdoor seating | Durable tile top and metal frame suit high-traffic hospitality patios | |
| Balcony large-space dining | Rectangular form fits narrow long balcony layouts for multi-person meals | |
| Recommended pairing | Matches 6 swivel or fixed cast aluminum patio dining chairs with cushions |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture safety requirements for seating and tables | |
|---|---|---|
| EN 581-2:2019 | Mechanical safety requirements for outdoor dining tables | |
| EN 12720:2009 | Test method for surface resistance to cold liquids for furniture |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for substrate inspection | |
|---|---|---|
| GB 28007-2011 | Safety requirements for children's furniture, applicable if used in family outdoor spaces | |
| GB/T 17657-2013 | Test methods for surface physical and chemical properties of wood-based panels |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for substrate inspection; 2. GB 28007-2011: Safety requirements for children's furniture, applicable if used in family outdoor spaces; 3. GB/T 17657-2013: Test methods for surface physical and chemical properties of wood-based panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
