Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1680 x 970 x 760 mm | |
|---|---|---|
| Tabletop slat thickness | 20 mm | |
| Tabletop slat gap width | 8 mm | |
| Floor-to-apron knee clearance | 680 mm | |
| X-base cross member leg section | 40 x 20 mm rectangular steel | |
| Steel frame wall thickness | 1.0 mm (20-gauge) | |
| Base footprint length | 1500 mm | |
| Base footprint width | 830 mm | |
| Per-seat table edge length per long side | 560 mm | |
| Tabletop edge overhang from frame | 40 mm | |
| Floor glide height | 5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net product weight | 28 kg | |
|---|---|---|
| Static distributed tabletop load capacity | 136 kg | |
| Recommended seating capacity | 6 people | |
| Frame finish corrosion resistance | 1000 hours salt spray resistance | |
| Tabletop UV stability rating | Grade 5 (ISO 105-B02) | |
| Surface temperature resistance range | -20 to 60 °C | |
| Warranty period | 2 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop slats | HDPE faux wood composite, wood-tone finish, UV-stabilized | |
|---|---|---|
| Support frame and X-base | Powder-coated carbon steel, matte black finish, 20-gauge wall thickness | |
| Assembly fasteners | Stainless steel 304 grade, rust-resistant | |
| Tabletop support rails | Powder-coated steel rectangular tubing, welded to base frame | |
| Floor glides | Injection-molded HDPE, non-marring, black | |
| Frame surface coating | E-coat primer plus polyester powder topcoat | |
| Tabletop edge profile | Rounded bullnose edge, smooth finish | |
| Structural weld points | Full penetration MIG welds, ground smooth at joints | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Surface drainage design | Evenly spaced gaps between slats direct rainwater off tabletop | |
|---|---|---|
| Floor protection function | Non-marring plastic glides prevent scratching of deck/patio surfaces | |
| Base stability design | X-cross bracing distributes load evenly across 4 ground contact points | |
| Assembly requirement | Knock-down assembly with pre-drilled components, included hex key hardware | |
| Weather resistance function | All-weather construction resists rot, rust, peeling, and cracking | |
| Chair tuck clearance | Full knee clearance allows 6 chairs to tuck completely under table edges | |
| Surface maintenance feature | Non-porous composite slats wipe clean with soap and water, no sealing required | |
| Leveling adjustment | Fixed-height glides with minor thread adjustment for uneven patio surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Packaging note | Engineering for preliminary quotation, not supplier measured | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyard decks, covered patios, and garden dining areas for family meals | |
|---|---|---|
| Commercial hospitality use | Appropriate for restaurant outdoor patios, café seating, and bistro dining areas | |
| Climate suitability | Rated for year-round outdoor use in temperate, coastal, and high-UV environments | |
| Surface compatibility | Safe for use on composite deck tiles, wood decks, concrete patios, and stone pavers | |
| Pairing recommendation | Designed to coordinate with matching slatted-back metal-frame outdoor dining armchairs | |
| Use case suitability | Supports casual meals, outdoor entertaining, and small patio gatherings |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating and table safety requirements for domestic use | |
|---|---|---|
| EN 581-2:2019 | Outdoor furniture mechanical safety and performance test methods for dining tables |
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk and table products performance standard, applicable for load and stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to table structural stability | |
|---|---|---|
| GB/T 28202-2011 | Outdoor furniture general technical requirements for material durability and safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to table structural stability; 2. GB/T 28202-2011: Outdoor furniture general technical requirements for material durability and safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
