Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1626 x 940 x 749 mm | |
|---|---|---|
| Tabletop slat thickness | 25 mm | |
| Leg profile (square) | 60 x 60 mm | |
| Leg wall thickness | 1.5 mm | |
| Central umbrella hole diameter | 66 mm | |
| Undertable knee clearance height | 680 mm | |
| Tabletop slat gap width | 8 mm | |
| Undertable cross support bar size | 40 x 20 mm | |
| Foot leveler height adjustment | 10 mm | |
| Edge overhang past leg line | 50 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 136 kg | |
|---|---|---|
| Product net weight | 21.3 kg | |
| Seating capacity | 6 people | |
| Finish UV resistance rating | 500 hours | |
| Finish salt spray resistance | 1000 hours | |
| Finish abrasion resistance | 2000 cycles | |
| Frame static load per leg | 45 kg | |
| Limited residential warranty | 12 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop slats | Cold-rolled steel slats with matte black powder coat | |
|---|---|---|
| Support legs | Square steel tube legs with e-coat primer under powder coat | |
| Undertable bracing | Rectangular steel cross support bars welded to leg frames | |
| Surface finish | Electrophoretic e-coat primer plus polyester powder topcoat | |
| Umbrella hole insert | Injection-molded plastic ring insert | |
| Foot levelers | Nylon adjustable foot pads with threaded steel stems | |
| Assembly hardware | Zinc-plated steel bolts, nuts, and washers | |
| Steel gauge for frame | 1.5 mm thick cold-rolled steel | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Slatted top drainage | Parallel slat gaps allow rainwater runoff to prevent pooling | |
|---|---|---|
| Center umbrella compatibility | Central hole accommodates standard patio umbrella poles up to 66 mm diameter | |
| Uneven surface adjustment | Threaded nylon foot levelers adjust to compensate for uneven patio stone | |
| Fixed rigid frame | Welded and bolted steel frame provides rigid non-wobble dining surface | |
| Weather resistance | Multi-layer coated steel resists rust, corrosion, and UV fading in exterior conditions | |
| Easy surface cleaning | Smooth matte powder coat surface wipes clean with water and mild detergent | |
| Residential outdoor use | Structure designed for patio, garden, deck, and backyard dining applications | |
| Standard dining height | 749 mm surface height accommodates standard outdoor dining armchairs | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio dining | Suitable for covered or open stone patios adjacent to lawns for family meals | |
|---|---|---|
| Backyard garden entertaining | Accommodates 6 guests for outdoor gatherings and casual meals | |
| Deck outdoor dining | Corrosion-resistant coating suitable for elevated wood or composite deck installations | |
| Poolside casual dining | Slatted top drainage and rust-resistant finish suitable for pool-adjacent use | |
| Balcony small-space dining | Compact 6-seat footprint fits medium to large residential balconies | |
| Commercial cafe outdoor seating | Durable steel construction suitable for light-duty commercial patio dining | |
| Recommended configuration | Pair with 6 matching slatted metal outdoor armchairs for a coordinated 7-piece dining set |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Safety requirements for outdoor residential seating and tables, applicable for design verification | |
|---|---|---|
| EN 581-2:2019 | Mechanical safety test methods for outdoor tables, applicable for load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural safety | |
|---|---|---|
| GB/T 17657-2013 | Surface finish test methods for furniture, applicable for coating durability verification | |
| GB 28007-2011 | Safety requirements for children's furniture if used in family outdoor spaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural safety; 2. GB/T 17657-2013: Surface finish test methods for furniture, applicable for coating durability verification; 3. GB 28007-2011: Safety requirements for children's furniture if used in family outdoor spaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
