Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 2500 x 2500 mm | |
|---|---|---|
| Table overall dimensions | 1500 x 1500 x 730 mm | |
| Table floor-to-apron knee clearance | 675 mm | |
| Center umbrella hole diameter | 40 mm | |
| Chair overall dimensions | 560 x 630 x 900 mm | |
| Chair seat height from floor | 450 mm | |
| Chair seat usable dimensions | 450 x 420 mm | |
| Chair backrest height above seat | 450 mm | |
| Chair armrest height above seat | 200 mm | |
| Slat width for table and chairs | 70 mm | |
| Table leg cross-section dimensions | 50 x 50 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Single chair static weight capacity | 136 kg | |
|---|---|---|
| Table top static distributed weight capacity | 136 kg | |
| Individual chair net weight | 14 kg | |
| Recommended maximum seating capacity | 6 adults | |
| Frame finish rust resistance service life | 3 years | |
| Surface weather resistance temperature range | -20 to 60 °C | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame material and finish | 1.2mm thick steel tube with matte black E-coat and powder coating | |
|---|---|---|
| Table top slat material | 20mm thick weather-resistant wood-plastic composite (WPC) faux wood slats | |
| Chair seat and back slat material | 15mm thick weather-resistant WPC faux wood slats, teak finish | |
| Armrest construction | 25mm diameter curved powder-coated steel tube integrated into chair frame | |
| Foot glides | Non-marking plastic adjustable foot glides fitted to leg bases | |
| Fastener hardware | Stainless steel rust-resistant bolts and screws for all assembly points | |
| Slat gap spacing | 8mm uniform gaps between parallel slats for water drainage | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Slatted surface drainage | Parallel 8mm gaps between slats allow rainwater to drain freely without pooling | |
|---|---|---|
| Center umbrella hole compatibility | 40mm diameter center hole accommodates standard patio umbrellas for sun shading | |
| Chair stacking capability | Chairs are designed to stack vertically for compact off-season storage | |
| Foot glide adjustment | Plastic foot glides adjust to compensate for uneven paved patio surfaces | |
| Fixed seating position | Chairs have non-swivel, non-reclining fixed frames suited for dining use | |
| Surface maintenance | Smooth WPC and powder-coated surfaces wipe clean with damp cloth for routine care | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Ideal for backyards, garden terraces, and balconies seating 6 for outdoor meals | |
|---|---|---|
| Commercial cafe seating | Suitable for outdoor bistro, coffee shop, and restaurant patio dining areas | |
| Poolside dining installation | Appropriate for pool decks, as WPC and coated steel resist chlorine and moisture damage | |
| Open-air event seating | Usable for outdoor weddings, community events, and pop-up dining spaces | |
| Recommended pairing | Pairs with a 38mm diameter patio umbrella for integrated sun shading over the table center | |
| Surface compatibility | Designed for use on paved stone, concrete, wood deck, and compacted gravel outdoor surfaces |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 Outdoor furniture - Seating and tables for camping, domestic and contract use | Applies to general safety requirements for outdoor domestic patio seating and tables | |
|---|---|---|
| EN 581-2:2019 Outdoor furniture - Mechanical safety requirements for seating | Applies to chair static load, stability, and durability performance testing for outdoor seating |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applies to dimensional stability, structural safety, and finish quality requirements for outdoor metal furniture used in China | |
|---|---|---|
| GB 28481-2012 Limit of harmful substances in plastic furniture | Applies to heavy metal and formaldehyde emission limits for WPC plastic composite slat components |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applies to dimensional stability, structural safety, and finish quality requirements for outdoor metal furniture used in China; 2. GB 28481-2012 Limit of harmful substances in plastic furniture: Applies to heavy metal and formaldehyde emission limits for WPC plastic composite slat components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
