| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 806 x 806 x 762 mm | |
|---|---|---|
| Tabletop edge thickness | 29 mm | |
| Central support column diameter | 102 mm | |
| 4-prong X-base overall width | 794 mm | |
| Underside knee clearance height | 700 mm | |
| Floor glide height | 5 mm | |
| Single base foot length | 380 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 150 kg | |
|---|---|---|
| Recommended seating capacity | 4 people | |
| Net product weight | 16 kg | |
| Finish scratch resistance rating | 3H | |
| Outdoor UV resistance lifespan | 3 years | |
| Base floor contact static load per foot | 41 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop construction | 1.2mm thick powder-coated steel sheet with rolled beveled edge | |
|---|---|---|
| Central support column | 2mm thick powder-coated steel cylindrical tube | |
| 4-prong X-base frame | 3mm thick powder-coated welded steel cross structure | |
| Surface finish | 80 micron matte white polyester powder coat | |
| Floor contact glides | Non-marking 5mm thick rubber pads | |
| Internal connection hardware | Zinc-plated M8 steel bolts and locking nuts | |
| Underside stability brace | 1.5mm thick steel cross bracket connecting column to tabletop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Assembly structure | Knock-down design with bolted connection between tabletop, column and base | |
|---|---|---|
| Floor protection | Rubber glides on each base foot prevent abrasion to concrete, stone or patio pavers | |
| Weather performance | Rust-resistant powder coat finish suitable for uncovered patio, poolside or cafe use | |
| Seating access | Central pedestal design provides unobstructed leg clearance on all four sides | |
| Surface stability | Welded X-base provides tip resistance for uneven paved outdoor surfaces | |
| Finish maintenance | Smooth matte surface wipes clean with standard outdoor furniture cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyards, balconies and garden dining areas seating 4people | |
|---|---|---|
| Commercial cafe bistro use | Rated for light commercial outdoor seating at coffee shops, bars and poolside areas | |
| Hospitality outdoor areas | Appropriate for hotel terraces, resort patios and outdoor event seating | |
| Surface compatibility | Safe for use on concrete pavers, stone patios, wood decking and tiled outdoor surfaces | |
| Climate suitability | Performs well in temperate, subtropical and coastal outdoor environments |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 Outdoor furniture - Seating and tables for camping, domestic and contract use | Applicable for general outdoor furniture safety requirements | |
|---|---|---|
| EN 581-3:2017 Outdoor furniture - Mechanical safety requirements for tables | Applicable for verifying structural stability and load performance |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for metal furniture | Applicable for structural safety, dimensional tolerance and finish quality inspection | |
|---|---|---|
| GB/T 17657-2013 Test methods for surface finish performance | Applicable for verifying scratch, abrasion and corrosion resistance of the powder coat |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for metal furniture: Applicable for structural safety, dimensional tolerance and finish quality inspection; 2. GB/T 17657-2013 Test methods for surface finish performance: Applicable for verifying scratch, abrasion and corrosion resistance of the powder coat; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
