Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 700 x 700 x 750 mm | |
|---|---|---|
| Tabletop diameter | 700 mm | |
| Tabletop thickness | 15 mm | |
| Central pedestal column diameter | 76 mm | |
| Cross base total span | 620 mm | |
| Base foot width | 60 mm | |
| Knee clearance height | 690 mm | |
| Tabletop edge radius | 8 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Net product weight | 12 kg | |
|---|---|---|
| Tabletop static load capacity | 68 kg | |
| Seating capacity | 2 persons | |
| Finish UV/rust resistance service life | 3 years | |
| Adjustable foot load rating per foot | 25 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Cast aluminum with uniform powder-coated finish | |
|---|---|---|
| Central support column | Powder-coated steel cylindrical tube | |
| 4-prong cross base | Powder-coated cast aluminum with integrated column joint | |
| Leveling foot pads | Thermoplastic rubber non-marking pads | |
| Assembly fasteners | Stainless steel rust-resistant screws and bolts | |
| Surface finish | Matte light beige weather-resistant polyester powder coat | |
| Tabletop edge trim | Integrally finished rounded metal edge | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Freestanding support | 4-point cross base distributes weight evenly for stable placement on hardscape | |
|---|---|---|
| Uneven surface adjustment | Threaded adjustable foot pads at each base end level table on sloped patios | |
| Weather resistance | Sealed powder-coated finish prevents rust, UV fading, and water damage | |
| Compact space use | Small pedestal footprint fits tight patio, balcony, or cafe seating areas | |
| Surface cleaning | Smooth non-porous tabletop wipes clean with standard household outdoor cleaners | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio/balcony | Compact 2-person size fits small outdoor residential seating zones | |
|---|---|---|
| Commercial sidewalk cafe | Durable all-weather construction withstands daily high-traffic outdoor use | |
| Poolside seating area | Rustproof finish resists chlorinated water and constant humidity exposure | |
| Garden gravel/stone seating nook | Stable cross base sits securely on uneven paved or gravel landscaping surfaces | |
| Temporary event seating | Lightweight construction allows easy repositioning for outdoor events |
EU Market Access Requirements* EN Standards
| Outdoor furniture structural safety | EN 581 | |
|---|---|---|
| Outdoor furniture mechanical safety | EN 581 | |
| Powder coating durability | EN 13438 |
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
