Automatic mm / inch conversion · Core engineering specifications
| Overall bench dimensions | 1850 x 660 x 940 mm | |
|---|---|---|
| Seat surface width | 1750 mm | |
| Seat surface depth | 480 mm | |
| Seat height from floor | 430 mm | |
| Backrest total height | 510 mm | |
| Armrest height from seat | 210 mm | |
| Matching side table dimensions | 610 x 610 x 690 mm | |
| Side table lower shelf height | 220 mm | |
| Bench leg splay width at floor | 1720 mm | |
| Cast component wall thickness | 4 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Bench total static load capacity | 330 kg | |
|---|---|---|
| Bench net weight | 18 kg | |
| Powder coating UV fade resistance | 500 hours | |
| Recommended user capacity | 3 adults | |
| Limited warranty period | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Bench and table frame | Sand-cast aluminum | |
|---|---|---|
| Exterior finish | Antique bronze powder coating | |
| Seat surface | Horizontal cast aluminum slats | |
| Backrest panel | Diamond-lattice cast aluminum | |
| Armrests | Curved ornate cast aluminum | |
| Bench legs | Splayed decorative cast aluminum | |
| Side table top | Perforated lattice cast aluminum | |
| Side table undershelf | Perforated cast aluminum | |
| Assembly hardware | Stainless steel bolts and nuts | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Outdoor weather performance | Fully rust-proof, water-resistant, UV-stable construction | |
|---|---|---|
| Seat drainage | Open slat seat design allows rainwater to drain freely | |
| Knock-down assembly | Bench and table ship flat with required hardware | |
| Surface maintenance | Wipe-clean smooth cast surfaces with no porous material | |
| Structural stability | Four-point splayed leg contact on both bench and table | |
| Ergonomic back support | Arched curved backrest with central lumbar medallion | |
| Armrest support | Wide curved armrests at both bench ends | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio installation | Suitable for wood/composite decks and stone patios | |
|---|---|---|
| Public park seating | Durable cast construction for high-traffic municipal green spaces | |
| Garden pathway placement | Positioned along walkways or next to garden beds for resting spots | |
| Porch and veranda use | Weatherproof construction for covered or uncovered front porch seating | |
| Balcony small-space set | Compact side table pairs with bench for narrow outdoor balconies |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating safety requirements, applicable for structural load and stability testing | |
|---|---|---|
| EN 581-2:2019 | Outdoor furniture mechanical performance requirements, applicable for seating durability validation | |
| EN 1022:2019 | Furniture seating stability test methods, applicable for bench tip resistance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural stability verification | |
|---|---|---|
| GB/T 17657-2013 | Surface coating performance test methods, applicable for powder coat adhesion and durability checks | |
| GB 28007-2011 | Furniture mechanical safety requirements, applicable for edge and sharp point hazard verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural stability verification; 2. GB/T 17657-2013: Surface coating performance test methods, applicable for powder coat adhesion and durability checks; 3. GB 28007-2011: Furniture mechanical safety requirements, applicable for edge and sharp point hazard verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
