Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (table centered, 4 chairs placed) | 1213 x 1213 x 953 mm | |
|---|---|---|
| Round table top diameter | 1213 mm | |
| Table overall height (floor to table top) | 762 mm | |
| Table central umbrella hole diameter | 51 mm | |
| Lower decorative lattice stretcher shelf size | 380 x 380 mm | |
| Single chair overall dimensions (W x D x H) | 566 x 668 x 953 mm | |
| Chair seat height (floor to seat surface) | 464 mm | |
| Chair seat usable dimensions (W x D) | 432 x 439 mm | |
| Chair backrest height (seat top to back crest) | 489 mm | |
| Curved armrest height above seat surface | 190 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight reference | 40 kg | |
|---|---|---|
| Per-chair static weight capacity | 180 kg | |
| Table top evenly distributed static load capacity | 91 kg | |
| Seating capacity for standard dining use | 4 people | |
| Recommended surface umbrella pole outer diameter compatibility | 50 mm | |
| Powder coating weather durability reference | 3 years | |
| Floor glide static scratch resistance load per foot | 45 kg | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top construction | Cast aluminum with openwork scroll perforations and raised decorative edge | |
|---|---|---|
| Table frame and legs | One-piece cast aluminum with curved splayed leg design | |
| Lower table lattice shelf | Cast aluminum open interlocking ring pattern, welded to central support column | |
| Chair frame and structural components | Cast aluminum integrated seat, back, arm and leg construction | |
| Chair seat surface | Cast aluminum perforated open scroll pattern for water drainage | |
| Chair backrest | Cast aluminum with raised floral and foliate scroll openwork design | |
| Surface finish | Antique bronze powder-coated rust-resistant outdoor coating | |
| Foot glides | Non-marking rounded plastic glides fitted to all leg bases | |
| Assembly hardware | Zinc-plated steel bolts and allen key fasteners for knock-down assembly | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central umbrella hole function | Accepts standard patio umbrella pole for outdoor shade, includes fitted cap for unused state | |
|---|---|---|
| Drainage performance | Open perforated design on table and chair surfaces allows 100% rainwater runoff without pooling | |
| Lower lattice shelf use | Provides decorative structural bracing and small item storage beneath table top | |
| Floor protection design | Raised non-marking glides on all feet prevent scratches to deck, patio, or tile surfaces | |
| Assembly requirement | Knock-down assembly of legs to table top and chair components, requires standard allen key | |
| Weather resistance | Rust-proof cast aluminum and sealed powder coating withstand rain, UV exposure and frost | |
| Stacking compatibility | Fixed leg design does not allow chair stacking for storage | |
| Armrest support | Integrated curved cast armrests provide forearm support during dining use | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio or balcony dining | Fits small 4-person outdoor dining spaces for private home garden or apartment balcony use | |
|---|---|---|
| Bistro or café outdoor seating | Commercial-grade styling suitable for small restaurant patio dining service areas | |
| Poolside leisure dining | Rust-resistant aluminum construction tolerates humid poolside environments without corrosion | |
| Sunroom or conservatory use | Ornate classic design works as decorative indoor dining furniture for enclosed sun spaces | |
| Small garden courtyard dining | Compact footprint fits landscaped courtyard spaces without requiring large floor area | |
| Deck or terrace casual dining | Non-marking glides protect wood or composite deck surfaces during regular use |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 Outdoor furniture - Seating and tables for domestic use - General safety requirements | Basic safety standard for structural stability and sharp edge inspection | |
|---|---|---|
| EN 581-2:2019 Outdoor furniture - Mechanical safety requirements for seating | Applies to chair static load, backrest fatigue and stability testing | |
| EN 581-3:2019 Outdoor furniture - Mechanical safety requirements for tables | Applies to table vertical load, impact and stability performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for metal furniture | Applies to structural dimensional tolerance and finish quality inspection for this metal dining set | |
|---|---|---|
| GB/T 17657-2013 Test methods for surface coatings on furniture | Applicable for verifying coating adhesion, abrasion and corrosion resistance of outdoor finishes | |
| GB 28007-2011 Safety requirements for children's furniture | Relevant if set is used in public family dining areas with child access |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for metal furniture: Applies to structural dimensional tolerance and finish quality inspection for this metal dining set; 2. GB/T 17657-2013 Test methods for surface coatings on furniture: Applicable for verifying coating adhesion, abrasion and corrosion resistance of outdoor finishes; 3. GB 28007-2011 Safety requirements for children's furniture: Relevant if set is used in public family dining areas with child access; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
