Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 2200 x 2200 x 900 mm | |
|---|---|---|
| Table dimensions | Φ1220 x 750 mm | |
| Table center umbrella hole diameter | 60 mm | |
| Single chair overall dimensions | 680 x 680 x 900 mm | |
| Chair seat height | 450 mm | |
| Chair seat dimensions | 500 x 500 mm | |
| Chair back height | 480 mm | |
| Chair armrest height | 650 mm | |
| Table under-clearance knee height | 680 mm | |
| Table pedestal leg spread diameter | 900 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 77 kg | |
|---|---|---|
| Per-chair static weight capacity | 136 kg | |
| Table top static weight capacity | 159 kg | |
| Seating capacity | 4 people | |
| Outdoor coating durability | 1000 hours salt spray resistance | |
| Cushion fabric abrasion resistance | 30000 cycles | |
| Seat cushion foam density | 35 kg/m³ | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame and top construction | Die-cast aluminum alloy, 4mm wall thickness | |
|---|---|---|
| Table and chair surface finish | Electrostatic polyester powder coating, white | |
| Chair frame construction | Solid die-cast aluminum, 3mm wall thickness | |
| Seat cushion fabric | 100% solution-dyed polyester, 0.6mm thickness | |
| Seat cushion padding | 35kg/m³ high-resilience polyurethane foam, 50mm thickness | |
| Table foot pads | Non-slip TPE rubber, 10mm thickness | |
| Hardware components | Stainless steel 304 fasteners | |
| Umbrella hole cover | Matching white cast aluminum cap | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Center umbrella mounting function | 60mm through-hole with fitted cap | |
|---|---|---|
| Adjustable leveling feet | 15mm thread adjustment travel on each table and chair leg | |
| Stackable chair storage | Chairs nest vertically when not in use | |
| Removable seat cushions | Hook-and-loop fastener attachment | |
| All-weather outdoor performance | Rust-proof cast aluminum and water-shedding fabric | |
| Lattice drainage function | Perforated table and chair back openwork | |
| Knock-down assembly | Includes full hardware kit and assembly tools | |
| Curved armrest support | Ergonomic contoured cast armrests | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential patio or deck use | Ideal for backyard, terrace or balcony outdoor dining for small families | |
|---|---|---|
| Garden and courtyard settings | Complements stone, wood or tile hardscaping in residential landscape designs | |
| Small commercial outdoor seating | Suitable for cafe patios, boutique hotel terraces and rooftop lounge areas | |
| Four-person casual meals | Configured for breakfast, lunch, afternoon tea or casual outdoor dinners | |
| All-season temperate climate use | Performs reliably in rain, sun and mild frost without rapid material degradation | |
| Coastal environment suitability | Powder-coated aluminum and stainless hardware resist salt air corrosion | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 Outdoor furniture - Seating and tables for camping, domestic and contract use - General safety requirements | Applicable baseline safety standard for all outdoor domestic patio furniture | |
|---|---|---|
| EN 581-2:2019 Outdoor furniture - Mechanical safety requirements for seating | Applicable for chair strength, stability and load testing of the armchairs | |
| EN 581-3:2017 Outdoor furniture - Mechanical safety requirements for tables | Applicable for table structural stability, load and impact performance testing |
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for metal furniture | Applicable for structural strength and finish quality inspection of metal outdoor furniture | |
|---|---|---|
| GB/T 17657-2013 Test methods for surface finishes of wood and metal furniture | Applicable for testing coating adhesion, hardness and abrasion resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for metal furniture: Applicable for structural strength and finish quality inspection of metal outdoor furniture; 2. GB/T 17657-2013 Test methods for surface finishes of wood and metal furniture: Applicable for testing coating adhesion, hardness and abrasion resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
