Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 1800 x 970 x 760 mm | |
|---|---|---|
| Tabletop slat gap | 8 mm | |
| Central umbrella hole diameter | 51 mm | |
| Overall chair dimensions | 580 x 640 x 890 mm | |
| Chair seat dimensions | 450 x 430 mm | |
| Chair seat height from floor | 460 mm | |
| Chair arm height from floor | 660 mm | |
| Chair backrest height | 410 mm | |
| Table underframe knee clearance | 660 mm | |
| Table leg cross-brace height | 280 mm | |
| Chair leg spread (base) | 560 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Total set net weight | 86 kg | |
|---|---|---|
| Per-chair static load capacity | 181 kg | |
| Seating capacity | 6 adults | |
| Frame rust resistance service life | 3 years | |
| HDPE slat UV fade resistance | 2000 hours | |
| Limited residential warranty | 2 years | |
| Available finish options | 2 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop slats | HDPE faux wood with light teak wood-grain finish | |
|---|---|---|
| Table frame and legs | 1.2mm thick powder-coated steel with matte black finish | |
| Table edge trim | Extruded aluminum black trim | |
| Chair seat and back slats | HDPE faux wood matching table finish | |
| Chair frames and armrests | 1.0mm thick powder-coated steel, curved continuous arm design | |
| Chair leg glides | Polypropylene plastic floor glides | |
| Fastener hardware | Stainless steel bolts and nuts | |
| Umbrella hole insert | Reinforced plastic ring | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Stackable chair storage | Chairs nest vertically for off-season storage | |
|---|---|---|
| Central umbrella compatibility | Fits standard 51 mm diameter patio umbrella poles | |
| Open slat drainage | Self-draining table and seat surfaces | |
| Leveling adjustment | Fixed non-adjustable glides | |
| Cleaning requirement | Washable with mild soap and water | |
| Cross-brace structural support | Table underframe cross bracing prevents lateral wobble | |
| Assembly requirement | Knock-down assembly with included hardware and tools | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyard decks, garden terraces, balcony dining areas | |
|---|---|---|
| Small commercial outdoor seating | Appropriate for cafe, bistro, or beer garden patio seating | |
| 6-person casual dining | Configured for family meals, small gatherings, or outdoor coffee service | |
| Umbrella-integrated shade setups | Compatible with standard market umbrellas for sun protection | |
| Low-maintenance outdoor spaces | Ideal for users requiring weatherproof furniture without annual staining or sealing | |
| Stackable storage environments | Suitable for venues requiring seasonal storage of outdoor seating | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture safety requirements for seating and tables, applicable to structural safety | |
|---|---|---|
| EN 581-2:2019 | Outdoor seating mechanical performance requirements, applicable to chair load testing | |
| EN 581-3:2019 | Outdoor table mechanical performance requirements, applicable to table stability testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to HDPE slat dimensional stability | |
|---|---|---|
| GB/T 4893.9-2013 | Surface resistance to dry heat, applicable to slat finish performance | |
| GB/T 17657-2013 | Physical and chemical property test methods for wood-based panels, applicable to HDPE panel testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to HDPE slat dimensional stability; 2. GB/T 4893.9-2013: Surface resistance to dry heat, applicable to slat finish performance; 3. GB/T 17657-2013: Physical and chemical property test methods for wood-based panels, applicable to HDPE panel testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
