Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 1560 x 970 x 750 mm | |
|---|---|---|
| Overall single armchair dimensions | 640 x 720 x 970 mm | |
| Table apron-to-floor knee clearance | 690 mm | |
| Seat height (floor to seat top) | 460 mm | |
| Single chair seat dimensions | 500 x 460 mm | |
| Chair back height (seat top to back top) | 510 mm | |
| Armrest height (floor to armrest top) | 640 mm | |
| Center umbrella hole diameter | 51 mm | |
| Table leg cross-section | 80 x 80 mm | |
| Slat width (table and chairs) | 70 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Single chair static weight capacity | 160 kg | |
|---|---|---|
| Distributed tabletop static load capacity | 75 kg | |
| Total set net weight | 72 kg | |
| Coating weather resistance lifespan | 3 years | |
| Stackable chair storage capacity per stack | 6 chairs | |
| Slat UV fade resistance rating | Grade 4 | |
| Frame rust protection performance | 500 hours salt spray resistance | |
| Adjustable foot pad height adjustment range | 15 mm | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table and chair frame | 1.2mm thick powder-coated steel with E-coat rust primer | |
|---|---|---|
| Tabletop slats | 20mm thick HDPE wood-composite faux teak slats | |
| Chair seat and back slats | 18mm thick HDPE wood-composite matching table slats | |
| Armrests | Powder-coated curved steel tubing with rounded edge finish | |
| Foot pads | Non-slip injection-molded PP plastic adjustable leveling pads | |
| Fastener hardware | Stainless steel 304 rust-resistant screws and bolts | |
| Frame surface finish | Matte black textured powder coat for scratch resistance | |
| Slat surface finish | Embossed wood grain texture for anti-slip performance | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Chair stackability | Armchairs stack vertically 6 units high for off-season storage | |
|---|---|---|
| Table leveling | Adjustable foot pads on each leg compensate for uneven paved or grass-adjacent surfaces | |
| Umbrella compatibility | Center hole accepts standard 48mm diameter patio umbrella poles | |
| Surface maintenance | Slat and frame surfaces wipe clean with damp cloth, no sealing or special treatment required | |
| Seating configuration | 6 armchairs arranged around table with 2 positions per long side, 1 per short side | |
| Hardware assembly | Knock-down assembly with included allen wrench and illustrated instructions | |
| Weather exposure suitability | Rated for full outdoor exposure to rain, sun, and temperature fluctuations | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Suitable for backyard paved patios, decks, or garden dining areas for family meals | |
|---|---|---|
| Commercial outdoor dining use | Applicable for cafe, bistro, or hotel terrace seating with regular cleaning maintenance | |
| Seating capacity | Accommodates 6 adults for full place setting dining, with sufficient elbow room per seat | |
| Climate suitability | Appropriate for temperate to subtropical climates with standard UV and rain exposure | |
| Recommended pairing | Compatible with standard 2.7m tall patio umbrellas and optional outdoor seat cushions | |
| Storage requirement | Chairs stack to minimize footprint when storing during off-season or inclement weather |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating and tables safety requirements for domestic use | |
|---|---|---|
| EN 581-2:2019 | Outdoor furniture mechanical safety requirements for seating, applicable to chair load tests | |
| EN 581-3:2017 | Outdoor furniture mechanical safety requirements for tables, applicable to table stability tests |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to frame and structural integrity checks | |
|---|---|---|
| GB/T 28203-2011 | Furniture hardware performance requirements, applicable to fastener and joint durability | |
| GB 18584-2001 | Indoor decorating materials limit of harmful substances for wood-based furniture, applicable to composite slat emission checks |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to frame and structural integrity checks; 2. GB/T 28203-2011: Furniture hardware performance requirements, applicable to fastener and joint durability; 3. GB 18584-2001: Indoor decorating materials limit of harmful substances for wood-based furniture, applicable to composite slat emission checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
