Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 950 x 950 x 740 mm | |
|---|---|---|
| Overall chair dimensions | 650 x 620 x 900 mm | |
| Chair seat height | 480 mm | |
| Chair seat width | 480 mm | |
| Chair seat depth | 460 mm | |
| Chair armrest height | 650 mm | |
| Under-table knee clearance height | 660 mm | |
| Tempered glass tabletop thickness | 5 mm | |
| Steel table leg diameter | 32 mm | |
| Steel cross-brace width | 25 mm | |
| Wicker weave strand width | 8 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set weight () | 50 kg | |
|---|---|---|
| Per-chair static load capacity | 160 kg | |
| Recommended seating capacity | 4 people | |
| Wicker UV fade resistance lifespan | 3 years | |
| Cushion foam density (if added) | 28D | |
| Limited manufacturer warranty | 2 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Woven body components | UV-stabilized brown PE wicker | |
|---|---|---|
| Structural frame (table + chairs) | Powder-coated rust-resistant steel tube | |
| Tabletop surface | Clear tempered safety glass over wicker base | |
| Chair armrests | Curved rattan-wrapped steel tube frame | |
| Table support bracing | Welded steel cross-bracing between legs | |
| Seat support webbing (internal) | Polypropylene elastic webbing | |
| Optional cushion fabric | Water-resistant 300D polyester | |
| Assembly hardware | Zinc-plated steel bolts and nuts | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Seating configuration | 4 fixed-position armchairs arranged around square table | |
|---|---|---|
| Table surface function | Smooth tempered glass top for easy spill cleanup | |
| Assembly requirement | Bolt-together assembly with included Allen key | |
| Weather resistance | Suitable for uncovered patio use with water-shedding wicker | |
| Floor protection | Plastic foot glides on all leg bottoms | |
| Stacking capability | Non-stacking fixed frame chair design | |
| Optional accessory fit | Compatible with 38mm diameter center umbrella poles | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Total packaged gross weight | 58 kg | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio placement | Suitable for stone or tile backyard terraces | |
|---|---|---|
| Small balcony dining | Fits compact 10 sqm outdoor balconies | |
| Commercial café seating | Appropriate for casual outdoor bistro or café use | |
| Leisure tea/coffee use | Supports small group casual drinks and light reading | |
| Poolside seating | Suitable for pool deck placement away from direct splash |
EU Market Access Requirements* EN Standards
| Outdoor furniture seating safety | EN 581:2017 | |
|---|---|---|
| Outdoor furniture table performance | EN 581:2017 | |
| Tempered glass for furniture | EN 12150:2015 |
Standards applicable to China-market projects
| Furniture mechanical performance for tables | GB/T 3324 | |
|---|---|---|
| Furniture mechanical performance for chairs | GB/T 3323 | |
| Tempered glass safety | GB 15763.2 |
This product must meet the following technical requirements: 1. Furniture mechanical performance for tables: GB/T 3324; 2. Furniture mechanical performance for chairs: GB/T 3323; 3. Tempered glass safety: GB 15763.2; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
