Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (table + 4 arranged chairs) | 1980 x 1980 x 729 mm | |
|---|---|---|
| Table overall dimensions | 1067 mm diameter x 729 mm height | |
| Center umbrella hole diameter | 40 mm | |
| Lower circular support shelf diameter | 530 mm | |
| Chair overall dimensions per unit | 570 mm wide x 640 mm deep x 991 mm high | |
| Chair seat height (floor to seat surface) | 432 mm | |
| Chair seat dimensions | 495 mm wide x 457 mm deep | |
| Chair backrest height (seat to top of back) | 508 mm | |
| Chair armrest height (floor to arm top) | 635 mm | |
| Table apron clearance (floor to table apron bottom) | 676 mm | |
| Metal slat width (table and chair surfaces) | 32 mm | |
| Table leg spread diameter at floor contact | 914 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-chair static weight capacity | 136 kg | |
|---|---|---|
| Table top distributed static load capacity | 68 kg | |
| Set total net weight (all components) | 39 kg | |
| Seating capacity | 4 adults | |
| Stacked chair storage height (4 chairs nested) | 1120 mm | |
| Coating UV fade resistance lifespan | 2 years | |
| Warranty period | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table and chair frame structure | 1.2 mm thick tubular steel with E-coat underlayer | |
|---|---|---|
| Exterior surface finish | Matte black weather-resistant polyester powder coating | |
| Tabletop construction | Horizontal 32mm wide steel slats with 5mm drainage gaps | |
| Chair seat and back construction | Horizontal steel slats welded to tubular frame | |
| Integrated chair armrests | Curved 22mm diameter tubular steel matching frame finish | |
| Lower table support shelf | Circular steel ring with cross-braced metal supports | |
| Chair foot pads | Non-slip polyethylene glides fitted to leg ends | |
| Umbrella hole fitting | Steel-rimmed opening with plastic insert ring | |
| Assembly hardware | Zinc-plated steel bolts, nuts and washers with hex key | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Center umbrella mounting | Accommodates standard 38mm diameter patio parasol poles with lower pole brace | |
|---|---|---|
| Chair stackable storage | Nests vertically up to 4 chairs for off-season space saving | |
| Slatted surface drainage | Open gaps between slats allow rainwater runoff without pooling | |
| Leveling adjustment | Replaceable foot glides compensate for slight uneven patio surfaces | |
| Knock-down assembly | Single-person assembly with included hardware and instruction manual | |
| Weather resistance performance | Multi-layer coating resists rust, rain exposure and UV fading for outdoor use | |
| Surface cleaning | Smooth powder-coated surface wipes clean with standard household outdoor cleaners | |
| Weighted umbrella base compatibility | Clear floor space under table accommodates 450mm diameter cast iron bases | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio/deck installation | Sized for small 4-person casual dining on home exterior paved surfaces | |
|---|---|---|
| Balcony outdoor use | Stackable storage supports use on small apartment balconies when not in use | |
| Garden and poolside placement | Weather-coated metal construction resists moisture and pool chemical exposure | |
| Casual outdoor dining and coffee service | Table height optimized for standard dining ware and beverage use | |
| Small commercial outdoor seating | Durable steel construction suitable for cafe or bistro exterior patio seating | |
| Umbrella-compatible shaded seating | Integrated umbrella hole supports adding a parasol for sun protection during daytime use |
EU Market Access Requirements* EN Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
