Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 580 x 620 x 890 mm | |
|---|---|---|
| Seat height from floor | 470 mm | |
| Seat width between armrests | 460 mm | |
| Seat depth front to back | 440 mm | |
| Backrest total height | 450 mm | |
| Armrest height from floor | 660 mm | |
| Armrest width | 35 mm | |
| Leg tube outer diameter | 28 mm | |
| Foot cap diameter | 30 mm | |
| X-cross stretcher height from floor | 190 mm | |
| Backrest oval width at widest point | 520 mm | |
| Backrest oval height | 400 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net chair weight | 5.8 kg | |
|---|---|---|
| Static weight capacity | 150 kg | |
| Recommended user weight | 120 kg | |
| Stackable storage height per chair | 90 mm | |
| UV exposure durability rating | 1500 hours | |
| Water ingress resistance | IPX4 | |
| Seat surface deflection under 100kg load | 12 mm | |
| Frame weld joint static load | 300 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main frame construction | 1.5 mm thick powder-coated aluminum tubing | |
|---|---|---|
| Seat and back weaving | UV-stabilized flat PE synthetic wicker, 8 mm width | |
| Armrest wrapping | Same PE wicker wrapped over curved aluminum arm core | |
| X-cross bracing bars | 1.2 mm thick powder-coated aluminum tubing | |
| Foot glides | Black non-slip polyethylene plastic caps | |
| Wicker binding joints | Tight woven PE wicker lashing at frame connection points | |
| Frame finish | Light beige matte powder coating | |
| Wicker surface texture | Tight basketweave pattern with open breathable gaps | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Fixed upright seating posture | Rigid welded frame with no recline or tilt mechanism | |
|---|---|---|
| Stackable storage capability | Nested vertical stacking up to 8 chairs high | |
| Integrated curved armrest support | Continuous arm loop from front seat edge to backrest for forearm rest | |
| Open weave drainage | Permeable woven seat and back allow rainwater to drain immediately | |
| Non-marring floor protection | Plastic foot glides prevent scratching hard patio or cafe floors | |
| X-brace structural stability | Dual cross stretchers reduce frame wobble on uneven outdoor surfaces | |
| Tool-free ready-to-use delivery | Fully welded assembled construction with no on-site assembly required | |
| Cushion compatibility | Flat woven seat accepts standard 40mm thick outdoor seat cushions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Outdoor cafe and bistro seating | Compact stackable design for high-turnover commercial patio dining | |
|---|---|---|
| Residential patio and balcony use | Lightweight weather-resistant construction for home outdoor dining areas | |
| Garden and poolside dining sets | UV and water resistant materials withstand exposed outdoor poolside conditions | |
| Hospitality outdoor event seating | Stackable design enables fast setup and compact storage for events | |
| Sidewalk restaurant dining zones | Narrow footprint maximizes seating capacity in limited sidewalk space | |
| Rooftop bar dining areas | Lightweight aluminum frame reduces structural load on rooftop surfaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Outdoor furniture seating safety and strength | EN 581:2017 | |
|---|---|---|
| Outdoor furniture mechanical safety requirements | EN 581:2019 |
Standards applicable to China-market projects
| Outdoor furniture general safety requirement | GB 28007 | |
|---|---|---|
| Furniture mechanical performance test for seating | GB/T 10357.3 | |
| Furniture surface cold crack resistance for outdoor use | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Outdoor furniture general safety requirement: GB 28007; 2. Furniture mechanical performance test for seating: GB/T 10357.3; 3. Furniture surface cold crack resistance for outdoor use: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
