Automatic mm / inch conversion · Core engineering specifications
| Overall table dimensions | 2000 x 1000 x 740 mm | |
|---|---|---|
| Central grill insert dimensions | 800 x 200 mm | |
| Armless fixed chair overall dimensions | 580 x 560 x 890 mm | |
| Seat height (all chairs) | 460 mm | |
| Armless chair seat dimensions | 480 x 460 mm | |
| Cushion thickness | 90 mm | |
| Table leg clearance height | 680 mm | |
| Chair backrest height (from seat) | 480 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Set net weight (total) | 100 kg | |
|---|---|---|
| Per-chair static weight capacity | 180 kg | |
| Table static weight capacity | 90 kg | |
| Recommended seating capacity | 6 diners | |
| Frame rust resistance service life | 3 years | |
| Cushion UV fade resistance rating | 500 hours | |
| Swivel rocker cycle durability | 20000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table and chair frames | Die-cast aluminum with e-coat plus bronze powder coat finish | |
|---|---|---|
| Tabletop surface | Inset ceramic tile with herringbone geometric pattern, black cast aluminum border | |
| Central grill insert | Black powder-coated steel with removable charcoal grate and drip tray | |
| Seat cushions | 90mm thick high-resilience polyurethane foam wrapped in beige solution-dyed polyester fabric | |
| Chair backrests | Cast aluminum lattice open-weave design with decorative embossed top rail | |
| Swivel rocker bases | Cast aluminum circular ring base with steel swivel and spring rocker mechanism | |
| Foot caps | Non-slip polyethylene adjustable levelers on all legs | |
| Assembly hardware | Zinc-plated steel bolts, nuts and washers with rust-resistant coating | |
| Seat cushion fasteners | Polyester tie straps to secure cushions to chair frames | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central integrated grill function | Recessed charcoal cooking surface accommodates skewers, grilled food and snacks with built-in utensil slot | |
|---|---|---|
| Swivel armchair movement | 4 armchairs support 360-degree rotation plus 15-degree backward rocking motion without tipping | |
| Armless chair configuration | 2 fixed armless chairs provide compact side seating that fits flush against the table edge | |
| Surface leveling | Adjustable polyethylene foot pads compensate for uneven deck or patio surfaces to eliminate table wobble | |
| Cushion attachment | Fabric tie straps secure beige cushions to chair seats to prevent sliding during use | |
| Grill maintenance access | Removable steel grill grate and drip tray lift out for easy cleaning after use | |
| Outdoor weather protection | Powder-coated frames and solution-dyed fabric resist rain, UV exposure and rust for year-round patio use | |
| Swivel armchair overall dimensions | 690 x 660 x 990 mm | |
| Swivel chair seat dimensions | 560 x 510 mm | |
| Swivel base diameter | 660 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Marking note | Engineering for preliminary quoting, not supplier-measured data | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio and deck dining | Suitable for backyard wood decks and stone patios adjacent to garden landscaping | |
|---|---|---|
| Casual outdoor grilling gatherings | Designed for 6-person meals with tabletop cooking for grilled snacks and skewers | |
| All-weather outdoor installation | Suited for permanent placement in temperate climates without seasonal storage | |
| Garden and courtyard entertaining | Ideal for family barbecues and small outdoor parties in residential courtyards | |
| Balcony and roof terrace use | Recommended for large covered balconies and roof terraces with sufficient space for 6 seats |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Safety requirements applicable to outdoor seating and dining furniture for residential use | |
|---|---|---|
| EN 581-2:2019 | Mechanical safety and stability test methods applicable to outdoor seating units | |
| EN 581-3:2017 | Mechanical safety and stability test methods applicable to outdoor dining tables |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements applicable to metal outdoor dining furniture stability and safety | |
|---|---|---|
| GB 28481-2012 | Restriction of hazardous materials applicable to furniture coatings and plastic components | |
| GB/T 16422.2-2013 | Xenon arc UV exposure test applicable to outdoor fabric and finish durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements applicable to metal outdoor dining furniture stability and safety; 2. GB 28481-2012: Restriction of hazardous materials applicable to furniture coatings and plastic components; 3. GB/T 16422.2-2013: Xenon arc UV exposure test applicable to outdoor fabric and finish durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
