Automatic mm / inch conversion · Core engineering specifications
| Table overall dimensions | 760 x 760 x 760 mm | |
|---|---|---|
| Tabletop diameter | 760 mm | |
| Table central column diameter | 76 mm | |
| Table cross base spread | 660 mm | |
| Table foot leveler height adjustment | 10 mm | |
| Chair overall dimensions | 530 x 510 x 880 mm | |
| Chair seat height | 460 mm | |
| Chair seat dimensions | 380 x 380 mm | |
| Chair backrest height above seat | 420 mm | |
| Chair armrest height above seat | 180 mm | |
| Chair leg taper thickness at foot | 20 mm | |
| Clearance under table for knee space | 660 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight | 54 kg | |
|---|---|---|
| Per-chair static load capacity | 150 kg | |
| Seating capacity | 4 persons | |
| Maximum chair stack height | 8 chairs | |
| Weather resistance rating | Indoor/outdoor UV and water resistant | |
| Limited warranty period | 1 year | |
| Available color variants | 5 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop construction | 1.2mm thick powder-coated solid steel | |
|---|---|---|
| Table pedestal column | 1.5mm thick welded steel tubing | |
| Table cross base frame | 2.0mm thick welded steel plate | |
| Chair frame construction | 1.2mm thick cold-rolled steel | |
| Surface finish | Matte black scratch-resistant polyester powder coat | |
| Floor protection glides | Hard nylon/rubber non-marring feet | |
| Adjustable levelers | Nylon-tipped steel thread inserts | |
| Seat and back panel | 1.0mm thick stamped steel | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Chair stackable storage | Chairs nest vertically for compact storage | |
|---|---|---|
| Table level adjustment | Threaded foot levelers compensate for uneven floors | |
| Wipe-clean surface maintenance | Smooth non-porous metal surfaces require only damp cloth cleaning | |
| Indoor/outdoor placement | Weather-resistant coating prevents rust and UV fading | |
| Table base stability design | 4-prong cross base eliminates leg obstruction around table | |
| Chair structural bracing | Welded horizontal cross bars under seat prevent frame flex | |
| Tool-free chair storage | No disassembly required for stacking chairs | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Largest carton dimensions | 800 x 800 x 100 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential balcony or small patio use | Compact 760mm diameter footprint fits tight outdoor spaces | |
|---|---|---|
| Commercial cafe or bistro seating | Durable steel construction and stackable design suit high-traffic venues | |
| Break room or casual office seating | Wipe-clean metal surface resists spills and daily wear | |
| Rooftop bar or beer garden use | Weather-resistant finish withstands outdoor sun and rain exposure | |
| Pop-up event or catering seating | Stackable chairs enable fast setup and compact transport between venues | |
| Studio apartment small dining area | Minimal industrial profile fits compact urban living spaces |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating and table safety requirements for residential use | |
|---|---|---|
| EN 581-2:2019 | Mechanical safety and strength test methods for outdoor seating | |
| EN 581-3:2017 | Mechanical safety and strength test methods for outdoor tables |
Standards applicable to China-market projects
| GB 28007-2011 | Applicable for children's furniture safety if used in family spaces | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for metal furniture performance testing | |
| GB/T 19995.1-2005 | Outdoor furniture metal material environmental adaptability requirements |
This product must meet the following technical requirements: 1. GB 28007-2011: Applicable for children's furniture safety if used in family spaces; 2. GB/T 3324-2017: General technical requirements for metal furniture performance testing; 3. GB/T 19995.1-2005: Outdoor furniture metal material environmental adaptability requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
