Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 1800 x 1800 x 850 mm | |
|---|---|---|
| Table top dimensions | 800 mm diameter, 1.0 mm steel thickness | |
| Table total height | 760 mm | |
| Central pedestal column diameter | 80 mm | |
| Table cross base width | 680 mm | |
| Chair overall dimensions | 450 x 490 x 850 mm | |
| Chair seat dimensions | 360 x 360 mm | |
| Chair seat height | 460 mm | |
| Chair backrest height | 390 mm | |
| Table knee clearance height | 680 mm | |
| Chair leg spread width | 440 mm | |
| Leveler adjustment range | 10 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Total set net weight | 28 kg | |
|---|---|---|
| Per-chair static load capacity | 150 kg | |
| Stackable chair storage height per 4 units | 850 mm | |
| Recommended seated user count | 4 people | |
| Powder coating scratch resistance | Grade 2, 500 abrasion cycles | |
| Structural warranty period | 1 year | |
| Available standard color count | 4 | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table top construction | 1.0 mm thick cold-rolled steel with matte black powder coat | |
|---|---|---|
| Table pedestal and base | 1.2 mm thick tubular cold-rolled steel, welded joints | |
| Chair frame and panels | 1.0 mm thick cold-rolled steel, one-piece pressed seat and back | |
| Surface finish | Matte black epoxy-polyester powder coating | |
| Table base levelers | M8 threaded nylon-capped adjustable feet | |
| Chair feet pads | Non-slip rubber caps pressed onto leg ends | |
| Joint construction | TIG welded steel connections at all frame joints | |
| Back panel detail | Embossed central vertical reinforcement rib | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Chair stacking function | Nested vertical stacking for up to 8 chairs | |
|---|---|---|
| Table level adjustment | Individual rotating feet on each cross base prong | |
| Table seating clearance | 360 degree unobstructed knee space around central pedestal | |
| Outdoor suitability | Rust-resistant powder coated steel construction | |
| Chair seating ergonomics | Curved integrated arm rests and sloped backrest | |
| Assembly requirement | Knock-down flat-pack assembly with included hardware | |
| Floor protection function | Rubber/nylon glides on all ground contact points | |
| Surface cleaning compatibility | Non-porous smooth powder coat finish | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Small cafe and coffee shop seating | Compact 4-seat footprint fits tight floor plans for casual dining | |
|---|---|---|
| Residential kitchen nook or breakfast area | Space-efficient round design works for small apartment dining spaces | |
| Covered outdoor patio seating | Rust-resistant powder coat finish withstands semi-outdoor conditions | |
| Breakroom and office pantry use | Durable commercial grade construction stands up to regular employee use | |
| Restaurant waiting or overflow seating | Stackable design allows quick deployment for peak service periods | |
| Pop-up event and catering seating | Lightweight, durable construction for repeated transport and setup |
EU Market Access Requirements* EN Standards
| EN 15372:2008 | Furniture - Strength, durability and safety for non-domestic seating | |
|---|---|---|
| EN 1730:2000 | Furniture - Test methods for tables | |
| EN 1022:2018 | Furniture - Seating - Determination of stability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture | |
|---|---|---|
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture coatings | |
| GB/T 10357.3-2013 | Seating furniture strength and durability test | |
| GB 18584-2001 | Limit of harmful substances for wooden furniture; reference for metal coating VOC |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture; 2. GB/T 4893.8-2013: Surface abrasion resistance test for furniture coatings; 3. GB/T 10357.3-2013: Seating furniture strength and durability test; 4. GB 18584-2001: Limit of harmful substances for wooden furniture; reference for metal coating VOC; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
