Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 940 x 940 x 760 mm | |
|---|---|---|
| Tempered glass tabletop thickness | 8 mm | |
| Metal frame tubing outer diameter | 38 mm | |
| Central circular footrest ring height above floor | 320 mm | |
| Footrest ring diameter | 300 mm | |
| Undertable knee clearance height | 660 mm | |
| Leg splay outer span at floor | 890 mm | |
| Metal tabletop rim width | 30 mm | |
| Non-marking foot pad diameter | 25 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total assembled product weight | 30 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 150 kg | |
| Frame finish weather durability | 500 hours salt spray resistance | |
| Tempered glass impact resistance | 1020 g steel ball drop from 1 m | |
| Recommended seating capacity | 4 people | |
| Limited consumer warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame construction | Welded tubular steel with hammered brown powder coat finish | |
|---|---|---|
| Tabletop panel | Smoked tinted tempered safety glass inset into metal rim | |
| Footrest ring | Matching powder-coated tubular steel welded to leg supports | |
| Foot pads | Non-marking non-slip rubber/polymer caps at each leg end | |
| Tabletop rim | Rolled metal edge with rounded corners to retain glass | |
| Frame connectors | Zinc-plated steel KD hardware for bolted assembly | |
| Frame wall thickness | 1.2 mm | |
| Powder coat finish thickness | 60 um | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Integrated footrest support | Central circular steel ring provides stable foot rest for all seated positions | |
|---|---|---|
| Knock-down assembly design | Frame and glass ship flat, assemble with included hex key and wrench in 50 minutes | |
| Surface cleaning compatibility | Glass top and powder coat frame wipe clean with mild detergent and soft cloth | |
| Outdoor stability design | Splayed curved legs distribute weight evenly to prevent tipping on paved patios | |
| Glass retention system | Raised metal rim surrounds inset glass to prevent lateral shift during use | |
| Surface protection feature | Non-marking foot pads prevent scuffs on stone, tile and wood deck surfaces | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential patio dining use | Suited for backyards, balconies and paved terrace spaces for 4-person meals | |
|---|---|---|
| Café and bistro outdoor seating | Appropriate for small commercial sidewalk dining areas paired with matching chairs | |
| Poolside leisure seating | Rust-resistant frame and easy-clean glass suitable for wet pool-deck environments | |
| Garden courtyard entertainment | Compact rounded-corner form fits small garden layouts without sharp edge hazards | |
| Apartment balcony dining | 940 mm square footprint fits standard small residential balcony spaces |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Outdoor furniture seating and table safety requirements for residential use | |
|---|---|---|
| EN 581-3:2017 | Outdoor furniture table mechanical safety and performance test methods | |
| EN 1096-1:2012 | Coated glass performance requirements applicable to tinted tabletop glass |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to frame and structure durability | |
|---|---|---|
| GB 15763.2-2005 | Safety glazing materials for building use, applicable to tempered glass tabletop safety | |
| GB/T 19001-2016 | Quality management system guideline for production consistency of outdoor furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to frame and structure durability; 2. GB 15763.2-2005: Safety glazing materials for building use, applicable to tempered glass tabletop safety; 3. GB/T 19001-2016: Quality management system guideline for production consistency of outdoor furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
