| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint | 2800 x 2400 x 910 mm | |
|---|---|---|
| Main rectangular dining table | 2130 x 1120 x 750 mm | |
| Stationary dining chair | 640 x 640 x 920 mm | |
| Side accent table | 600 x 600 x 500 mm | |
| Cushioned seat height | 480 mm | |
| Seat cushion dimensions | 510 x 480 x 90 mm | |
| Chair armrest height | 660 mm | |
| Table umbrella hole diameter | 50 mm | |
| Side table lower shelf height | 200 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Per-chair static weight capacity | 113 kg | |
|---|---|---|
| Table top static load capacity | 100 kg | |
| Set total net weight | 110 kg | |
| Powder coat UV fade resistance | 500 hours | |
| Cushion fabric abrasion resistance | 15000 cycles | |
| Swivel rocker mechanism cycle rating | 20000 motions | |
| Frame corrosion resistance | Salt spray rated for 1000 hours | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main frame construction | 3mm thick cast aluminum | |
|---|---|---|
| Table top surface | Cast aluminum lattice openwork | |
| Seat cushion core | 90mm thick quick-dry polyurethane foam | |
| Cushion upholstery fabric | 180g/m2 solution-dyed polyester | |
| Swivel rocker mechanism hardware | Zinc-plated steel bushings and springs | |
| Chair and table leg feet | High-density polyethylene glide pads | |
| Side table lower shelf | Cast aluminum lattice panel | |
| Cushion fasteners | Polyester tie straps | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Swivel rocker chair motion | 360° smooth rotation plus 12° backward rocking | |
|---|---|---|
| Cushion maintenance | Removable, machine-washable cushion covers | |
| Table umbrella compatibility | Center 50mm umbrella hole with matching cast metal cover | |
| Openwork drainage design | Lattice openings on all table and chair backs | |
| Assembly requirement | Knocked-down assembly with included hex key and hardware | |
| Stationary chair stability | Four fixed cast aluminum legs with floor glides | |
| Side table multi-use | Dual-level surface for serving, decor, or side storage | |
| Surface weather performance | Heat-dispersing cast aluminum surfaces | |
| Swivel rocker dining chair | 640 x 640 x 920 mm | |
| Swivel rocker base ring diameter | 660 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Total shipment volume | 1.1 CBM | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio dining | Seats 6 adults comfortably for outdoor meals, gatherings, and tea service | |
|---|---|---|
| Garden or courtyard placement | Rust-resistant bronze finish blends with stone, wood, and landscaped surroundings | |
| Covered balcony use | Scaled for large covered balcony or terrace entertainment spaces | |
| Target user group | Homeowners seeking durable, low-maintenance traditional outdoor dining furniture | |
| Recommended complementary items | 9ft bronze patio umbrella, outdoor rug, and matching patio storage cover | |
| Suitable climate zones | All non-extreme coastal and temperate climate zones |
EU Market Access Requirements* EN Standards
| Outdoor furniture mechanical safety | EN 581:2017 | |
|---|---|---|
| Outdoor furniture durability performance | EN 581:2019 |
Standards applicable to China-market projects
| Outdoor furniture metal frame requirement | GB/T 3324 | |
|---|---|---|
| Outdoor furniture fabric safety | GB 18401 | |
| Furniture surface coating resistance | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Outdoor furniture metal frame requirement: GB/T 3324; 2. Outdoor furniture fabric safety: GB 18401; 3. Furniture surface coating resistance: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
