Automatic mm / inch conversion · Core engineering specifications
| Overall set footprint (in use) | 1900 x 1900 mm | |
|---|---|---|
| Table overall dimensions | 940 x 940 x 750 mm | |
| Table umbrella hole diameter | 50 mm | |
| Table apron clearance height | 676 mm | |
| Table slat width | 70 mm | |
| Table leg tubing outer diameter | 32 mm | |
| Chair overall dimensions | 615 x 615 x 890 mm | |
| Chair seat height | 432 mm | |
| Chair seat depth | 430 mm | |
| Chair seat width | 560 mm | |
| Chair backrest height | 450 mm | |
| Chair armrest height from seat | 180 mm | |
| Chair leg tubing outer diameter | 25 mm | |
| Chair slat thickness | 20 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Table static weight capacity | 100 kg | |
|---|---|---|
| Single chair static weight capacity | 200 kg | |
| Total set net weight | 48 kg | |
| Seating capacity | 4 adults | |
| Frame coating salt spray resistance | 500 hours | |
| Slat UV stability rating | Grade 4 | |
| Stacked chair storage height (4 units) | 1200 mm | |
| Surface temperature resistance | 70 °C | |
| Warranty period for structural parts | 3 years | |
| Reference Static Load | 150 kg depending on category |
Core acceptance fields · Panels / hardware / frame / upholstery
| Table frame material | 1.2mm thick powder-coated carbon steel | |
|---|---|---|
| Tabletop slat material | Weather-resistant wood-look HDPE composite | |
| Chair frame material | 1.0mm thick black powder-coated tubular steel | |
| Chair seat/back slat material | Matching light brown wood-look HDPE slats | |
| Foot pad material | Non-slip non-scratch PP plastic | |
| Umbrella hole fitting | Black PP plastic ring with matching cap | |
| Frame surface finish | Matte black textured powder coating | |
| Hardware material | 304 stainless steel fasteners | |
| Stabilizer cross brace | 20mm square steel tube under tabletop | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central umbrella hole function | Accommodates standard patio umbrellas with cap for covered use when not holding umbrella | |
|---|---|---|
| Chair stackability feature | All four chairs stack vertically for compact off-season storage | |
| Slatted surface drainage | 8mm gaps between table and chair slats drain rainwater quickly to prevent pooling | |
| Adjustable foot pad function | Rotating leveling feet compensate for uneven patio/deck surfaces | |
| Tool-included assembly | All required hex keys and hardware provided for 2-person assembly | |
| Weather-resistant performance | Frame and slats resist rain, UV and temperature changes without regular sealing | |
| Armrest load support | Curved steel armrests support up to 50kg of vertical load per side | |
| Modular placement flexibility | Chairs can be positioned on any side of the square table for flexible layout | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Residential patio use | Ideal for backyard decks, stone patios and balcony dining areas for 4 people | |
|---|---|---|
| Small outdoor café use | Suitable for light commercial bistro and coffee shop outdoor seating areas | |
| Garden leisure use | Perfect for outdoor tea, meals and casual gatherings next to planters or lawns | |
| All-weather placement | Designed for year-round outdoor use without covering in mild climates | |
| Balcony application | Fits small 2x2m+ urban balconies for compact outdoor dining | |
| Recommended accessory pairing | Pairs with 2m patio umbrella and optional 4cm thick outdoor seat cushions |
EU Market Access Requirements* EN Standards
| EN 581-1:2017 | Safety requirements for outdoor seating and tables for residential use | |
|---|---|---|
| EN 581-2:2019 | Mechanical strength and durability test methods for outdoor furniture | |
| EN 1022:2018 | Stability testing for domestic seating furniture |
Standards applicable to China-market projects
| GB 28007-2011 | Applies to mechanical safety requirements for children and adult outdoor furniture | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for metal furniture dimensional stability | |
| GB/T 17657-2013 | Test method for surface finish wear and corrosion resistance |
This product must meet the following technical requirements: 1. GB 28007-2011: Applies to mechanical safety requirements for children and adult outdoor furniture; 2. GB/T 3324-2017: General technical requirements for metal furniture dimensional stability; 3. GB/T 17657-2013: Test method for surface finish wear and corrosion resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
