| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall chair dimensions | 840 x 900 x 1050 mm | |
|---|---|---|
| Ottoman overall dimensions | 630 x 530 x 430 mm | |
| Seat height | 400 mm | |
| Seat width | 560 mm | |
| Seat depth | 540 mm | |
| Backrest height | 650 mm | |
| Armrest height above seat | 180 mm | |
| Ottoman seat height | 400 mm | |
| Cushion thickness (seat) | 100 mm | |
| Cushion thickness (back/headrest) | 80 mm | |
| Seat width between armrests | 560 mm | |
| Seat cushion depth | 540 mm | |
| Backrest total height from seat | 650 mm | |
| Armrest height above seat surface | 180 mm | |
| Seat cushion thickness | 100 mm | |
| Back and headrest cushion thickness | 80 mm |
Net weight / load capacity / users / durability
| Total set net weight | 33 kg | |
|---|---|---|
| Static load capacity (chair) | 160 kg | |
| Recommended user weight | 120 kg | |
| Upholstery abrasion resistance | 50000 cycles | |
| Seat cushion density | 45 kg/m³ | |
| Back cushion density | 38 kg/m³ | |
| Foam rebound rate | 60% | |
| Swivel rotation range | 360 degrees | |
| Warranty period | 3 years | |
| Recommended maximum user weight | 120 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer shell panels | Molded bent plywood with light walnut veneer finish | |
|---|---|---|
| Upholstery (black sections) | Top-grain leather or high-grade PU faux leather | |
| Upholstery (tan side sections) | Matching tan leather/PU upholstery on inner shell edges | |
| Inner cushion core | High-resilience polyurethane foam with Dacron wrap | |
| Swivel frames (chair and ottoman) | Powder-coated matte black steel four-star base | |
| Central support stem | Walnut-veneer wrapped steel column | |
| Swivel bearing | Zinc-plated steel thrust bearing | |
| Floor glides | Hard nylon non-marking glides | |
| Frame internal structure | Die-cast aluminum connection brackets between shell segments | |
| Black upholstery sections | Top-grain leather or high-grade PU faux leather, 1.2mm thickness | |
| Tan side upholstery trim | Matching tan leather/PU upholstery on inner shell edges, stitched to black cushion panels | |
| Chair and ottoman swivel bases | Powder-coated matte black steel four-star base, 2.5mm wall thickness |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel (chair) | Full rotation on central thrust bearing, no tilt lock, fixed recline angle of 118 degrees from horizontal | |
|---|---|---|
| 360-degree swivel (ottoman) | Independent full rotation on matching central bearing, allowing flexible leg positioning relative to chair | |
| Padded armrest support | Integrated padded armrests fixed to seat shell, positioned to support forearms at 180mm above seat surface | |
| Integrated headrest support | Contoured fixed headrest aligned to support the cervical spine in semi-reclined position, no height or angle adjustment | |
| Matching ottoman leg rest | Coordinated height ottoman to support fully extended legs, reducing lower back pressure when used with the chair | |
| No height adjustment | Fixed seat height, no gas lift height adjustment, stationary lounge posture designed for living room, study or lounge area use | |
| Stitch construction | Double-stitched seams at upholstery panel joints, 8mm stitch pitch for seam durability | |
| Floor protection | Non-marking nylon glides fitted to all base leg ends to prevent scratching hard wood, tile or laminate flooring | |
| Swivel base diameter (chair) | 700 mm | |
| Swivel base diameter (ottoman) | 600 mm | |
| Chair 360-degree swivel | Full unobstructed rotation on central thrust bearing, fixed recline angle of 118 degrees from horizontal, no active tilt mechanism or tilt lock | |
| Ottoman 360-degree independent swivel | Full unobstructed rotation on matching central thrust bearing, no mechanical connection to the chair base |
Verified carton / gross weight / assembly / loading data
| Chair carton dimensions | 870 x 720 x 820 mm | |
|---|---|---|
| Ottoman carton dimensions | 660 x 560 x 460 mm | |
| Total gross weight per set | 40 kg | |
| Total CBM per set | 0.69 | |
| Assembly time | 30 minutes | |
| 20ft container loading quantity | 38 sets | |
| 40ft HQ container loading quantity | 93 sets | |
| Packaging materials | 5-layer corrugated carton, EPE foam wrap, hard corner protectors, plastic bag for hardware kit | |
| Chair export carton dimensions | 870 x 720 x 820 mm | |
| Ottoman export carton dimensions | 660 x 560 x 460 mm |
Recommended spaces / users / usage modes
| Residential living room use | Placed in living rooms or reading nooks for relaxed reading, media viewing or casual lounging, paired with the matching ottoman for full leg support | |
|---|---|---|
| Executive office lounge use | Installed in executive office waiting areas or private office relaxation zones for guest or executive use, matching mid-century modern office decor | |
| Hospitality lounge application | Used in hotel lobbies, boutique guest room seating areas or premium lounge spaces for guest comfort, with durable upholstery suited for regular commercial use | |
| Home study/den placement | Positioned in home studies or libraries as a dedicated reading and relaxation seat, with compact footprint fitting small to medium sized rooms | |
| Recommended placement clearance | Minimum 800mm clearance behind chair to allow full swivel and access, 400mm front clearance to extend ottoman fully | |
| Color option availability | Available in 3 standard upholstery color combinations: all black, black/tan (as shown), walnut shell/white upholstery; custom upholstery colors available for bulk orders | |
| Residential living room placement | Positioned in living rooms, reading nooks or media rooms for relaxed reading, television viewing or casual lounging, paired with the matching ottoman for full leg support | |
| Executive office lounge installation | Installed in executive office waiting areas, private office relaxation zones or boardroom breakout spaces for guest or executive use |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture - Strength, durability and safety for domestic seating, applicable to static load and durability testing for residential use | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable to tip resistance testing for chair and ottoman on level surfaces | |
| EN 14465:2005 | Furniture - Upholstery fabrics - Specification for coated fabrics for furniture, applicable to leather/PU upholstery performance testing for heavy use |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to molded plywood shell structural integrity and finish quality inspection | |
|---|---|---|
| GB 28007-2011 | Safety requirements for upholstered furniture, applicable to upholstery flame retardance and structural safety for domestic use | |
| GB/T 16799-2008 | Specification for polyurethane leather for furniture, applicable to upholstery material performance testing if PU upholstery is specified |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to molded plywood shell structural integrity and finish quality inspection; 2. GB 28007-2011: Safety requirements for upholstered furniture, applicable to upholstery flame retardance and structural safety for domestic use; 3. GB/T 16799-2008: Specification for polyurethane leather for furniture, applicable to upholstery material performance testing if PU upholstery is specified; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
