Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 660 x 680 x 1120 mm | |
|---|---|---|
| Seat height from floor | 480 mm | |
| Seat width | 510 mm | |
| Seat depth | 490 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest height from seat | 710 mm | |
| Backrest width at widest point | 490 mm | |
| Armrest height from seat | 210 mm | |
| Armrest length | 280 mm | |
| Five-star base diameter | 680 mm | |
| Caster diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight range | 22 kg | |
|---|---|---|
| Maximum static user load capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Backrest foam density | 38 kg/m³ | |
| Foam rebound rate | 45% | |
| Gas lift class rating | Class 3 | |
| Gas lift stroke length | 100 mm | |
| Caster rolling durability cycles | 100000 cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | Top-grain brown semi-aniline leather, 1.2mm thickness | |
|---|---|---|
| Backrest upholstery | Top-grain brown semi-aniline leather, 1.2mm thickness | |
| Armrest pads | Brown padded leather over molded foam, matching seat upholstery | |
| Seat internal support | 12mm thick molded plywood panel under foam | |
| Backrest internal frame | 15mm thick bent plywood structural frame | |
| Five-star base | Polished die-cast aluminum alloy, 2.5mm wall thickness | |
| Gas lift and column | Chrome-plated steel Class 3 gas lift with polished outer column | |
| Armrest supports | Polished cast aluminum brackets connecting armrests to seat frame | |
| Casters | Black nylon hard-floor casters with chrome mounting stems | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full 360° horizontal rotation enabled by central gas lift swivel mechanism | |
|---|---|---|
| Seat height adjustment | 100mm vertical height adjustment via Class 3 gas lift, operated by side lever | |
| Tilt function | Synchronized seat and back tilt up to 12 degrees, with tension adjustment knob | |
| Tilt lock function | Single-position tilt lock to secure upright seating posture | |
| Smooth rolling mobility | Dual-wheel hard-floor casters for low-friction movement on tile, wood and low-pile carpet | |
| Fixed armrest support | Rigid fixed armrests to support forearms during desk work at standard desk height | |
| High-back lumbar support | Contoured bent backrest providing built-in lumbar support without separate adjustment | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 carton | |
|---|---|---|
| Shipping carton dimensions | 880 x 680 x 580 mm | |
| Gross shipping weight | 26 kg | |
| Shipping volume (CBM) | 0.35 CBM | |
| Assembly time | 25 minutes | |
| 40ft HQ container loading quantity | 180 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set |
Recommended spaces / users / usage modes
| Executive private offices | Formal high-back leather design suitable for director and management private offices, presenting a professional appearance | |
|---|---|---|
| Meeting and conference rooms | Fixed padded armrests and supportive structure suitable for extended meeting use around conference tables | |
| Client reception areas | Premium brown leather and polished chrome finish creates a refined first impression for visitor seating | |
| Open plan management workstations | Swivel and mobility features support daily desk work while maintaining an executive aesthetic | |
| Commercial flooring environments | Hard nylon casters are suitable for tile, polished stone and low-pile carpet common in commercial offices | |
| Standard height office desks | 480mm seat height is ergonomically matched to standard 760 mm high office desks seen in the image | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | European office chair standard for dimensional, strength and durability requirements for commercial task seating | |
|---|---|---|
| EN 1335-2:2020 | European safety, strength and durability test methods applicable for structural validation of this chair | |
| EN 1022:2018 | European standard for seating stability verification, applicable for tip resistance testing |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 Clause 5 | Base static load test requirement of 1136kg minimum for five-star office chair bases | |
|---|---|---|
| Base static load capacity | 1136 kg |
Standards applicable to China-market projects
| GB 20210-2006 | Chinese standard for fire resistance of upholstered furniture seating components, applicable for upholstered seat and back | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to chrome-plated metal base and structural frame components |
This product must meet the following technical requirements: 1. GB 20210-2006: Chinese standard for fire resistance of upholstered furniture seating components, applicable for upholstered seat and back; 2. GB/T 3324-2017: General technical requirements for metal furniture, applicable to chrome-plated metal base and structural frame components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
