Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 680 x 700 x 1180 mm | |
|---|---|---|
| Seat height range (from floor) | 520 mm | |
| Seat width (between side supports) | 500 mm | |
| Seat depth (front edge to backrest) | 480 mm | |
| Backrest total height (from seat top to headrest top) | 720 mm | |
| Headrest height (from backrest top seam) | 220 mm | |
| Integrated armrest height (from seat top) | 220 mm | |
| Bentwood side panel thickness | 12 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight (fully assembled) | 25 kg | |
|---|---|---|
| Maximum static user weight capacity | 150 kg | |
| Recommended maximum daily usage duration | 8 hours | |
| Seat foam density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Foam rebound rate | 45% | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Caster rolling durability cycle count | 40000 cycles | |
| Base static load capacity | 1136 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | White smooth faux leather (PU), 1.0mm thickness, with matching white edge piping | |
|---|---|---|
| Seat padding | Cold-cure high-resilience polyurethane foam, 80mm thick at seat center | |
| Backrest padding | Molded polyurethane foam, 50mm thick at lumbar support zone | |
| Side structural accents | Dark walnut veneer over bent plywood frame, with clear satin lacquer finish | |
| Swivel base | Polished chrome-plated steel, 2mm tube wall thickness, 5-star radial design | |
| Height adjustment component | Class 3 chrome-plated steel gas lift, 50mm outer diameter | |
| Swivel/tilt chassis | 2.5mm thick cold-rolled steel, black powder-coated internal finish | |
| Casters | Dual-wheel polyurethane tread casters with chrome-plated yoke, 50mm wheel diameter | |
| Edge trim | Thin black contrast piping along outer upholstery seams, with white topstitch | |
| Internal back frame | 15mm thick multi-layer plywood, glued and stapled to bentwood side structure | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full circular rotation around central gas lift axis, with no rotational stops, enabled by precision bearing in central chassis | |
|---|---|---|
| Pneumatic seat height adjustment | 100mm vertical travel, controlled by side lever under seat, locks at any height within travel range, activated while seated | |
| Tilt tension and lock | Synchronized seat and back tilt up to 12 degrees backward from upright position, with adjustable tension knob under seat and upright position lock | |
| Smooth caster mobility | Five dual-wheel casters roll freely on hard tile, wood, or low-pile carpet flooring, with no braking mechanism as standard | |
| Integrated lumbar support | Fixed contoured foam support at mid-lumbar zone aligned to 220 mm above seat surface, providing passive posture support without adjustable mechanism | |
| Integrated headrest support | Fixed upper headrest section aligned to cervical spine height when seated upright, providing passive neck support for tall users | |
| Fixed integrated armrests | Curved armrest surfaces formed by upholstered padding over bentwood side panels, providing fixed forearm support at 220mm above seat surface | |
| 5-star swivel base diameter | 660 mm | |
| Gas lift stroke length | 100 mm | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 850 x 670 x 640 mm | |
| Gross shipping weight per carton | 29 kg | |
| Shipping volume per unit (CBM) | 0.37 CBM | |
| Typical assembly time per unit | 20 minutes | |
| 20ft GP container loading quantity | 178 units | |
| 40ft HQ container loading quantity | 440 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Executive private offices | Suitable for manager or director private office spaces, with modern two-tone white and walnut finish matching contemporary desk systems shown in product photo | |
|---|---|---|
| Open-plan workstations | Suitable for premium open-plan office seating for senior staff, with muted neutral finish that coordinates with light or dark office furniture palettes | |
| Conference and meeting rooms | Suitable for boardroom or formal meeting room seating, with high-back support and polished chrome accents creating a professional, upscale appearance | |
| Home office spaces | Suitable for high-end residential home office use, with easy-clean faux leather upholstery and elegant wood trim complementing modern residential interior design | |
| Client reception areas | Suitable for executive reception or visitor seating, with comfortable padding and refined aesthetic creating a positive first impression for guests | |
| Hard flooring environments | Optimized for tile, polished concrete, or wood flooring, with polyurethane casters that roll smoothly without scratching hard floor surfaces | |
| Standard desk height compatibility | Designed for use with 760 mm high standard office desks, with seat height adjustment range ensuring correct ergonomic elbow alignment with desk surfaces | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applicable European standard for office chair dimensional safety and performance requirements, recommended for export orders to EU markets | |
|---|---|---|
| EN 1335-2:2018 | Applicable standard for office chair structural strength, durability and stability, recommended for commercial project procurement verification | |
| EN 1022:2018 | Applicable standard for furniture seating stability testing, recommended to confirm tip resistance during normal use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable standard for general-purpose office chairs, recommended for commercial US market orders to verify back strength, base load and cyclic durability | |
|---|---|---|
| ANSI/BIFMA X5.11-2015 | Applicable standard for bariatric office chair load ratings if specifying higher capacity, base standard unit rated for general office use |
Standards applicable to China-market projects
| GB/T 16432-2015 | Applicable standard for caster durability on rolling office seating, recommended for verifying caster wear performance and rolling resistance | |
|---|---|---|
| GB 20214-2022 | Applicable standard for sharp edge access on office furniture, recommended to confirm no hazardous sharp edges on metal base or wood panels |
This product must meet the following technical requirements: 1. GB/T 16432-2015: Applicable standard for caster durability on rolling office seating, recommended for verifying caster wear performance and rolling resistance; 2. GB 20214-2022: Applicable standard for sharp edge access on office furniture, recommended to confirm no hazardous sharp edges on metal base or wood panels; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
