Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 680 x 700 x 1280 mm | |
|---|---|---|
| Seat height adjustable range | 440 to 540 mm | |
| Seat width | 520 mm | |
| Seat depth | 500 mm | |
| Backrest height | 760 mm | |
| Headrest dimensions | 460 x 180 mm | |
| Armrest height above seat | 220 mm | |
| Five-star base diameter | 700 mm | |
| Caster diameter | 60 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest padding thickness | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight range | 27 kg | |
|---|---|---|
| Maximum recommended user weight | 150 kg | |
| Gas lift stroke | 100 mm | |
| Backrest tilt angle range | 90 to 120 degrees | |
| Caster rolling durability | 100000 cycles | |
| Seat edge static load rating | 75 kg | |
| Standard warranty period | 5 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | 1.4mm thick top-grain black leather | |
|---|---|---|
| Seat cushion padding | 80mm thick high-density polyurethane foam | |
| Backrest padding | 50mm thick high-density polyurethane foam | |
| Structural shell | 12mm thick bent plywood with walnut wood veneer finish | |
| Armrest structure | Polished die-cast aluminum frame with padded leather top surface | |
| Five-star base | Polished die-cast aluminum alloy, 3mm wall thickness | |
| Gas lift | Class 3 chrome-plated steel gas lift, 50mm outer diameter | |
| Tilt mechanism | 3mm thick steel multi-lock synchro-tilt chassis | |
| Casters | 60mm diameter black polyurethane swivel casters with steel stem | |
| Seam construction | Bonded nylon thread with 8 stitches per 30mm seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seat height adjustment | Pneumatic adjustment via right-side lever, 100mm travel range to fit 1900 mm user height | |
|---|---|---|
| Backrest recline function | Synchro-tilt mechanism with 3-position lock, tilts backrest at 1:1.3 ratio relative to seat pan, 30 degree maximum recline angle | |
| Tilt tension adjustment | Rotary knob under seat adjusts recline resistance to match user weight between 150 kg | |
| 360-degree swivel function | Full rotational swivel around central gas lift axis for easy access to desk surfaces without repositioning the base | |
| Mobility function | Five dual-wheel polyurethane casters enable smooth rolling on hard floors and low-pile commercial carpet with 12kg rolling resistance | |
| Integrated headrest support | Padded fixed-position headrest aligned to support cervical spine during upright and reclined seating positions | |
| Fixed arm support | Curved padded armrests positioned at 220mm above seat to support forearms and reduce shoulder strain during desk work | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 870 x 680 x 630 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.373 CBM | |
| Required assembly time | 25 minutes | |
| 20ft GP container loading quantity | 90 units | |
| 40ft HQ container loading quantity | 220 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Executive private offices | Suits premium executive offices with walnut wood trim, formal professional appearance for management and C-suite users | |
|---|---|---|
| Corporate boardrooms | Matches formal conference room aesthetics for director-level seating around boardroom tables with standard 760 mm desk height | |
| High-end home offices | Fits luxury home workspaces with leather and wood finish, comfortable for 8 hour daily work sessions | |
| Commercial client meeting rooms | Provides professional, durable seating for visiting clients in law firms, financial institutions and executive service environments | |
| Adjustability for mixed user groups | 100mm seat height adjustment and tilt tension control accommodates users 1900 mm tall across different user populations | |
| Flooring compatibility | Polyurethane casters work safely on hard wood, tile and low-pile commercial carpet without floor protection mats for standard use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applies to office chair dimensional safety and performance requirements for office work chairs, baseline for ergonomic sizing verification | |
|---|---|---|
| EN 1335-2:2018 | Applies to strength, durability and stability requirements for office swivel chairs, minimum performance threshold for commercial use | |
| EN 1022:2018 | Applies to seating stability testing, ensuring resistance to forward, rearward and sideways tipping during normal use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 Clause 17 | Applies to caster durability testing, requiring 100000 cycle rolling performance without failure for commercial use chairs | |
|---|---|---|
| Seat static load capacity | 1136 kg |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applies to size measurement of office chairs, defining standard dimensions for seat height, width, depth and backrest dimensions for procurement verification | |
|---|---|---|
| GB/T 3324-2017 | Applies to general technical requirements for wood furniture, covering surface finish quality, structural strength and dimensional tolerance for the bent plywood shell | |
| GB/T 22792.1-2009 | Applies to stability, strength and durability requirements for office swivel chairs, minimum performance baseline for commercial procurement | |
| GB 18584-2001 | Applies to formaldehyde emission limits for wood-based furniture components, mandatory requirement for indoor commercial furniture sold in China |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applies to size measurement of office chairs, defining standard dimensions for seat height, width, depth and backrest dimensions for procurement verification; 2. GB/T 3324-2017: Applies to general technical requirements for wood furniture, covering surface finish quality, structural strength and dimensional tolerance for the bent plywood shell; 3. GB/T 22792.1-2009: Applies to stability, strength and durability requirements for office swivel chairs, minimum performance baseline for commercial procurement; 4. GB 18584-2001: Applies to formaldehyde emission limits for wood-based furniture components, mandatory requirement for indoor commercial furniture sold in China; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
