Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 620 x 680 x 1020 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 480 mm | |
| Seat width | 500 mm | |
| Backrest height | 550 mm | |
| Backrest width | 480 mm | |
| Armrest height above seat | 220 mm | |
| Sled base width | 580 mm | |
| Sled base depth | 620 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest padding thickness | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 14 kg | |
|---|---|---|
| Maximum static load capacity | 150 kg | |
| Recommended user weight limit | 120 kg | |
| Backrest flex deflection under 100kg load | 12 degrees | |
| Seat foam density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Foam rebound rate | 45% | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Net product weight | 14 kg | |
| Recommended occupant weight limit | 120 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest upholstery | 1.0mm thick brown PU faux leather | |
|---|---|---|
| Seat core padding | High-density polyurethane foam | |
| Backrest core padding | Molded high-density polyurethane foam with horizontal segmented stitching | |
| Armrest support structure | 25mm diameter chrome-plated steel tubing | |
| Armrest top pads | Injection-molded black polyurethane, soft-touch finish | |
| Cantilever sled base | 1.5mm thick polished chrome-plated steel tube, continuous bent frame | |
| Floor contact glides | Injection-molded nylon anti-scuff glides | |
| Internal backrest support panel | 12mm thick molded plywood | |
| Upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Cantilever support frame | 1.5mm wall thickness polished chrome-plated steel tube, continuous bent one-piece sled structure | |
| Armrest support brackets | 25mm diameter chrome-plated steel tubing, welded to main sled frame for rigid support | |
| Frame connection hardware | Zinc-plated steel bolts and lock washers, securing seat/back assembly to steel frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating support | Fixed cantilever sled frame provides gentle controlled flex when seated, no tilt or swivel mechanism | |
|---|---|---|
| Arm support function | Fixed-height 220mm armrests provide consistent forearm support during seated meetings, with no height, width, or angle adjustment capability | |
| Lumbar support | Contoured segmented backrest with raised horizontal padding provides built-in mid-back lumbar support, no adjustable lumbar mechanism | |
| Floor protection | Integrated nylon glides prevent scratching hard floor surfaces, allow gentle repositioning without lifting the chair | |
| Stacking capability | Non-stacking fixed frame design, intended for permanent placement around conference tables | |
| Cleaning and maintenance | Smooth PU upholstery can be wiped clean with standard non-abrasive office cleaning products, no removable cushion covers | |
| Assembly requirement | Delivered partially assembled, requiring attachment of armrest/frame components to seat back unit with included hardware | |
| Seating support mechanism | Fixed cantilever sled frame provides 12 degrees of controlled gentle flex when occupied, with no swivel, tilt, or height adjustment mechanisms | |
| Lumbar support function | Contoured segmented backrest with raised 60mm thick horizontal padding provides built-in mid-back lumbar support, with no adjustable lumbar mechanism | |
| Floor protection function | Integrated nylon glides prevent scratching of hard floor surfaces, allowing low-force repositioning without lifting the chair | |
| Cleaning maintenance | Smooth non-porous PU upholstery can be wiped clean with standard non-abrasive office cleaning products, with sewn-in non-removable cushion covers | |
| Static stability performance | Wide 590mm sled base provides 10 degree tipping resistance when unoccupied, meeting commercial seating stability requirements |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 piece per carton | |
|---|---|---|
| Shipping carton dimensions | 670 x 520 x 600 mm | |
| Gross shipping weight | 16 kg | |
| Shipping volume per unit (CBM) | 0.21 CBM | |
| Assembly time per unit | 20 minutes | |
| 20ft GP container loading quantity | 320 units | |
| 40ft HQ container loading quantity | 760 units | |
| Packaging materials | 5-layer corrugated carton, expanded polystyrene edge protection, polyethylene bag wrap, included hardware kit with allen key | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Conference room seating | Suitable for placement around meeting and boardroom tables, with fixed stable design and professional appearance for client and internal meetings | |
|---|---|---|
| Visitor and guest seating | Ideal for reception areas, executive office guest positions, and waiting areas, with polished chrome frame and leather-look upholstery providing a formal professional aesthetic | |
| Training room seating | Appropriate for corporate training rooms and seminar spaces, with durable upholstery and stable base that prevents unwanted movement during sessions | |
| Hard floor compatibility | Suitable for use on tile, hardwood, laminate, and sealed concrete floors with integrated anti-scuff glides that prevent floor damage | |
| Carpet compatibility | Suitable for low to medium pile carpeted offices, with wide sled base that distributes weight to avoid excessive sinking into carpet pile | |
| Matching desk configuration | Pairs with executive desks, conference tables, and reception counters with standard 750 mm work surface height, with 450mm seat height matching standard desk ergonomics | |
| Available upholstery color options | Offered in black, brown, and dark gray PU upholstery for coordination with standard office interior palettes | |
| Reception visitor seating | Ideal for reception areas, executive office guest positions, and corporate waiting zones, with polished chrome frame and leather-look upholstery projecting a professional formal aesthetic |
EU Market Access Requirements* EN Standards
| EN 1335-1:2000 | Office furniture - Office work chair - Part 1: Dimensions - safety requirements, applicable for dimensional ergonomic verification | |
|---|---|---|
| EN 1335-2:2009 | Office furniture - Office work chair - Part 2: Safety requirements, applicable for structural strength and stability testing | |
| EN 1022:2005 | Domestic furniture - Seating - Determination of stability, applicable for cantilever chair tipping resistance verification | |
| EN 15373:2007 | Furniture - Strength, durability and safety - Requirements for non-domestic seating, applicable for contract-grade visitor chair durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 Test 5 | Backrest static load test: 667N force applied to backrest for 1 minute, with no structural failure or permanent deformation |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for internal structural plywood components | |
|---|---|---|
| GB/T 3325-2017 | General technical requirements for metal furniture, applicable for chrome-plated steel frame strength and finish durability | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable for formaldehyde emission limits from internal panel components | |
| GB/T 29601-2013 | General technical requirements for office furniture, applicable for overall chair stability, static load and durability performance | |
| GB/T 39222-2020 | Office furniture - Visitor chair, applicable to dimensional ergonomics, structural safety, and test methods for fixed visitor seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for internal structural plywood components; 2. GB/T 3325-2017: General technical requirements for metal furniture, applicable for chrome-plated steel frame strength and finish durability; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable for formaldehyde emission limits from internal panel components; 4. GB/T 29601-2013: General technical requirements for office furniture, applicable for overall chair stability, static load and durability performance; 5. GB/T 39222-2020: Office furniture - Visitor chair, applicable to dimensional ergonomics, structural safety, and test methods for fixed visitor seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
