Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 610 x 640 x 930 mm | |
|---|---|---|
| Seat height adjustment range | 530 mm | |
| Seat cushion usable dimensions | 490 x 450 mm | |
| Seat cushion thickness | 70 mm | |
| Backrest dimensions | 500 x 470 mm | |
| 4-star base diameter | 640 mm | |
| Gas lift outer column diameter | 50 mm | |
| Shell edge trim thickness | 8 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 15 kg | |
|---|---|---|
| Maximum static user weight capacity | 136 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 45% | |
| Swivel rotation | 360 degrees | |
| Surface abrasion resistance (upholstery) | 50000 double rubs (Martindale) | |
| Base static load rating | 450 kg | |
| Recommended warranty period | 3 years | |
| Upholstery Martindale abrasion resistance | 50000 double rubs | |
| 4-star base static load rating | 450 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | Cognac tan polyurethane faux leather, 1.2mm thickness | |
|---|---|---|
| Structural shell | 12mm bent laminated plywood with walnut wood grain veneer finish | |
| Seat cushion core | High resilience polyurethane foam wrapped with 10mm soft Dacron batting | |
| Backrest padding | 20mm thick molded polyurethane foam | |
| Adjustment gas lift | Class 3 carbon steel pneumatic cylinder with polished chrome outer sleeve | |
| 4-star base | Polished die-cast aluminum, 3mm wall thickness | |
| Height adjustment lever | Injection-molded black nylon lever | |
| Base foot pads | 15mm diameter non-marking black rubber glides | |
| Edge trim | Matching faux leather welt binding along all plywood shell edges | |
| Structural bentwood shell | 12mm bent laminated plywood with walnut wood grain veneer finish | |
| 4-star swivel base | Polished die-cast aluminum, 3mm wall thickness | |
| Base foot glides | 15mm diameter non-marking black rubber glides |
Adjustment / rotation / tilt / mobility / storage features
| Pneumatic seat height adjustment | 100mm vertical travel controlled by side-mounted lever, activated while seated to adjust seat height to match desk or table surface | |
|---|---|---|
| 360-degree swivel rotation | Unobstructed full rotation around central vertical axis with no tilt or lock functionality, enabling easy orientation toward meeting participants without moving the base | |
| Stationary fixed base | No rolling casters, rubber glides rest directly on floor for stable positioning in conference or visitor settings | |
| Integrated fixed armrests | Curved continuous armrests formed as part of the bent plywood shell, padded along upper surface matching seat upholstery, fixed at 70mm above seat surface | |
| Mid-back lumbar support | Contoured backrest angled 10 degrees from vertical to provide passive lower back support without adjustable lumbar hardware | |
| No tilt mechanism | Fixed seat-to-back angle of 98 degrees, no recline, tilt tension adjustment or tilt lock present, suited for upright task and meeting use | |
| Integrated curved arm ledges | Continuous curved armrests formed as part of the bent plywood shell, padded along upper surface with matching upholstery, fixed at 70mm above seat surface for forearm support during meetings | |
| Mid-back passive lumbar support | Contoured backrest angled 10 degrees from vertical to provide lower back support without adjustable lumbar hardware, aligned for upright meeting posture | |
| Fixed seat-back angle | 98 degree fixed angle between seat and backrest, no recline, tilt tension adjustment or tilt lock present, suited for upright task and meeting use | |
| Base leg height from floor to swivel joint | 380 mm | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 670 x 670 x 580 mm | |
| Gross shipping weight | 18 kg | |
| Shipping volume per unit | 0.26 CBM | |
| Assembly time | 15 minutes | |
| 20ft GP container loading quantity | 210 units | |
| 40ft HQ container loading quantity | 520 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate conference rooms | Ideal for boardroom and meeting table seating, with stationary glides that prevent unwanted rolling and a slim profile that slides fully under standard 750mm high conference tables | |
|---|---|---|
| Executive office visitor seating | Suitable for guest seating in private offices, with a polished mid-century aesthetic that complements wood executive desks and case goods | |
| Co-working open meeting areas | Appropriate for informal collaboration zones, with 360-degree swivel that allows easy reorientation between teammates during discussions | |
| Hospitality lounge and workspace seating | Suitable for hotel business centers and boutique lounge work areas, with durable faux leather upholstery that resists staining and is easy to clean | |
| Home office task seating | Compatible with residential workspaces, with a compact footprint and neutral finish that blends with modern home interiors without bulky ergonomic chair aesthetics | |
| Hard flooring surfaces | Designed for use on wood, tile and polished concrete floors, with non-marking rubber glides that prevent floor scuffing without the need for a chair mat | |
| Hospitality business center seating | Suitable for hotel business centers and boutique lounge work areas, with durable faux leather upholstery that resists staining and wipes clean with standard disinfectants | |
| Hard flooring installations | Designed for use on wood, tile and polished concrete floors, with non-marking rubber glides that prevent floor scuffing without requiring a chair mat |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Applicable European standard for office work chairs: dimensional and safety requirements for fixed-height and adjustable seating | |
|---|---|---|
| EN 1335-2:2018 | Applicable European standard for office work chairs: safety requirements for structural strength, stability and durability testing | |
| EN 1021-1:2014 | Applicable upholstered furniture flammability standard: resistance to ignition by smouldering cigarette |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Applicable North American standard for office chairs: general purpose requirements for strength, durability and stability of non-tilt task seating | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Applicable furniture sustainability standard for material content, emissions and end-of-life disassembly for commercial seating |
Standards applicable to China-market projects
| GB/T 3326-2016 | Applicable standard for office furniture: chair and stool dimensional tolerances, to be verified for seat height, width and depth measurements | |
|---|---|---|
| GB 28007-2011 | Applicable stability, strength and durability standard for office chairs, covering static load, impact and fatigue testing requirements | |
| GB/T 16799-2008 | Applicable standard for polyurethane synthetic leather used in furniture upholstery, covering abrasion, color fastness and tear strength |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Applicable standard for office furniture: chair and stool dimensional tolerances, to be verified for seat height, width and depth measurements; 2. GB 28007-2011: Applicable stability, strength and durability standard for office chairs, covering static load, impact and fatigue testing requirements; 3. GB/T 16799-2008: Applicable standard for polyurethane synthetic leather used in furniture upholstery, covering abrasion, color fastness and tear strength; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
