| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| overall assembled dimensions | 680 x 680 x 950 mm | |
|---|---|---|
| seat width | 480 mm | |
| seat depth | 460 mm | |
| seat height adjustment range maximum | 590 mm | |
| seat height adjustment range minimum | 500 mm | |
| backrest height | 480 mm | |
| 5-star base span diameter | 700 mm | |
| caster wheel diameter | 60 mm | |
| gas lift cylinder diameter | 50 mm | |
| gas lift adjustable stroke | 100 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| net weight range maximum | 16 kg | |
|---|---|---|
| recommended static user weight capacity | 136 kg | |
| seat foam density | 45 kg/m³ | |
| backrest foam density | 35 kg/m³ | |
| foam rebound rate | 60% | |
| upholstery abrasion resistance | 50000 Martindale cycles | |
| caster rolling durability | 40000 rolling cycles | |
| gas lift static load rating | 150 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat and backrest upholstery | 1.0mm thick polyurethane (PU) faux leather, camel tan color | |
|---|---|---|
| seat cushion padding | 60mm thick high-density polyurethane foam | |
| backrest padding | 40mm thick high-density polyurethane foam | |
| internal seat support panel | 12mm thick molded plywood | |
| internal support frame | 1.5mm thick powder-coated steel tubing | |
| 5-star base | 1.2mm thick chrome-plated steel tubing, polished mirror finish | |
| central gas lift cylinder | Chrome-plated steel Class 3 pneumatic cylinder | |
| seat mechanism plate | 2.5mm thick steel tilt mechanism with black powder coat finish | |
| caster wheels | Black polyurethane (PU) dual-wheel hooded casters, non-marking | |
| upholstery stitching | Matching tan thread with 8mm seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full unlimited 360° rotation around central gas lift axis, enabled by precision bearing in seat mechanism | |
|---|---|---|
| pneumatic seat height adjustment | One-touch lever-operated height adjustment with 100mm vertical travel, locking securely at any position within stroke | |
| seat tilt/rock function | 12-degree backward tilt with adjustable tension control, locking in upright position for focused work | |
| rolling mobility | Smooth omnidirectional movement on hard smooth flooring via 5 dual-wheel PU casters, no brake function as standard | |
| ergonomic contour support | Integrated curved bucket seat and winged mid-back design providing lower back and lateral thigh support without protruding armrests | |
| floor protection | Non-marking PU caster material prevents scuffs and scratches on hardwood, tile, and laminate flooring without requiring separate chair mats | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 1 | |
|---|---|---|
| shipping carton dimensions | 750 x 650 x 450 mm | |
| shipping gross weight | 16 kg | |
| shipping volume per unit | 0.22 CBM | |
| assembly time | 50 minutes | |
| 20ft GP container loading quantity | 120 units | |
| 40ft HQ container loading quantity | 290 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| home office workspaces | Suitable for home study and desk setups, with compact armless design fitting tight desk spaces and camel tan finish complementing modern, mid-century, and minimalist interior decor | |
|---|---|---|
| small office workstation use | Suitable for open-plan small workstations and hot-desking environments, with 360° swivel and rolling mobility for easy access to adjacent desk surfaces without armrest obstruction | |
| vanity/makeup desk use | Suitable for bedroom vanity and dressing table use, with bucket seat contour providing comfortable support during extended grooming sessions and height adjustment matching standard vanity table heights | |
| temporary meeting/guest seating | Suitable for temporary guest seating in office meeting areas and reception spaces, with easy rolling movement for flexible reconfiguration and easy-to-clean faux leather surface resisting light stains | |
| hard floor surface use | Recommended for use on tile, hardwood, laminate, and vinyl flooring, with non-marking PU casters preventing scuffs and scratches without requiring a separate chair mat | |
| light daily use recommendation | Designed for 6 hours of daily seated use, suitable for remote work, study, and casual computer use rather than 8+ hour heavy commercial ergonomic applications | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 applicability | Applies to dimensional and safety requirements for office work chairs, defining minimum clearance, stability, and adjustment range criteria for task seating | |
|---|---|---|
| EN 1335-2:2018 applicability | Applies to strength, durability, and stability performance requirements for office chairs, including cyclic load testing for seats, backs, and bases | |
| EN 1335-3:2009 applicability | Applies to test methods for verifying compliance with EN 1335 dimensional and safety requirements for office seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 caster test requirement | Applies to caster durability and floor protection performance, requiring minimum 40000 rolling cycles without failure or excessive floor wear | |
|---|---|---|
| 5-star base static load rating | 1134 kg |
Standards applicable to China-market projects
| GB/T 3326-2016 applicability | Applies to dimensional measurement and tolerance verification of office desk chairs, defining standard test methods for overall and functional dimensions | |
|---|---|---|
| GB/T 10357.3-2013 applicability | Applies to mechanical safety and strength testing of office chairs, including static load, fatigue, and stability test requirements for seating structures | |
| GB 28007-2011 applicability | Applies to general safety requirements for children's and adult office seating, covering sharp edges, structural stability, and hazardous material limits |
This product must meet the following technical requirements: 1. GB/T 3326-2016 applicability: Applies to dimensional measurement and tolerance verification of office desk chairs, defining standard test methods for overall and functional dimensions; 2. GB/T 10357.3-2013 applicability: Applies to mechanical safety and strength testing of office chairs, including static load, fatigue, and stability test requirements for seating structures; 3. GB 28007-2011 applicability: Applies to general safety requirements for children's and adult office seating, covering sharp edges, structural stability, and hazardous material limits; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
Export data is generated from the current published product record.
Directly download an English report in metric or imperial units.
Download all product information and parameter modules in English.
English title, specifications, materials, standards and purchasing fields.
Prepare customs description, material, usage, dimensions and declaration elements.
