Automatic mm / inch conversion · Core engineering specifications
| Overall assembled dimensions | 660 x 686 x 977 mm | |
|---|---|---|
| Seat width | 483 mm | |
| Seat depth | 470 mm | |
| Seat height adjustment range from floor | 574 mm | |
| Five-star base diameter/span | 686 mm | |
| Backrest height from seat surface | 578 mm | |
| Armrest height from seat surface | 203 mm | |
| Caster wheel diameter | 50 mm | |
| Gas lift cylinder outer diameter | 50 mm | |
| Seat cushion thickness at center | 80 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Recommended maximum user weight capacity | 159 kg | |
|---|---|---|
| Net product weight | 15 kg | |
| Maximum backrest recline/tilt angle from upright | 15° | |
| Seat swivel rotation range | 360° | |
| Upholstery abrasion resistance (Martindale double rubs) | 100000 | |
| Caster rolling durability cycles | 100000 | |
| 5-star base static load rating | 477 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest outer upholstery | Two-tone black with light blue accent PU faux leather, 1.0 mm thickness | |
|---|---|---|
| Seat cushion padding | High-resiliency polyurethane foam, 50 kg/m³ density, 40% rebound rate | |
| Backrest padding | Molded polyurethane foam, 40 kg/m³ density, 35 mm thickness | |
| Inner support shell | 12 mm thick molded plywood or high-impact polypropylene | |
| 5-star base | 1.5 mm thick chrome-plated polished steel | |
| Pneumatic gas lift cylinder | Class 3 steel cylinder, 100 mm stroke, chrome finish | |
| Caster wheels | Black nylon dual-wheel casters with 11 mm x 22 mm grip ring steel stems | |
| Tilt and height adjustment mechanism | 2.5 mm thick steel plate chassis with black plastic adjustment lever | |
| Seam stitching | Bonded polyester thread, 8 stitches per inch seam pitch | |
| Protective floor contact pads on casters | Soft TPE tread on nylon wheel hubs | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Pneumatic seat height adjustment | Single left-side under-seat lever controls gas lift to adjust seat height between 475 mm and 574 mm from floor, with infinite lock between stops | |
|---|---|---|
| Basic tilt/rocking function | Single-position upright lock with adjustable tension control, allowing up to 15 degrees of backward rock from neutral upright position | |
| Rolling mobility | Five dual-wheel casters allow 360-degree omni-directional movement on hard floors and low-pile commercial carpet | |
| Integrated fixed armrest support | Curved upholstered side bolsters integrated into the seat shell provide fixed forearm support without height or width adjustment | |
| Mid-back ergonomic support | Contoured backrest shaped to support the natural lumbar curve for upright desk work posture, with no separate adjustable lumbar pillow | |
| Quick assembly design | Tool-light knock-down assembly requiring attachment of casters to base, gas lift insertion, and seat unit mounting without complex fasteners | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Shipping carton dimensions | 650 x 600 x 350 mm | |
|---|---|---|
| Gross shipping weight per carton | 15 kg | |
| Shipping volume (CBM) per unit | 0.137 | |
| Required assembly time per unit | 30 minutes | |
| 40-foot HQ container loading quantity | 430 units | |
| Included packaging components | 1 upholstered seat/back/arm shell assembly, 1 chrome 5-star base, 5 dual-wheel casters, 1 Class 3 gas lift cylinder, 1 steel tilt mechanism, hardware kit, assembly instruction manual | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set |
Recommended spaces / users / usage modes
| Home office workspace | Ideal for compact home desks and study areas, with small footprint matching residential room dimensions and modern two-tone aesthetic for residential interiors | |
|---|---|---|
| Open-plan office workstation zones | Suitable for commercial open office areas, meeting rooms and hot-desking setups with durable chrome base and contract-grade abrasion-resistant upholstery | |
| Conference and meeting rooms | Mid-back profile and modern design provide professional appearance for boardrooms and collaborative meeting spaces without bulky executive chair dimensions | |
| Reception and guest waiting areas | Approachable two-tone color scheme and rolling mobility work for reception seating where staff may need to adjust position while greeting visitors | |
| Vanity and makeup desk use | Adjustable seat height and supportive backrest make it suitable for bedroom vanity stations, with smooth casters that move easily on hard bedroom flooring | |
| Co-working shared spaces | Durable construction and easy-clean faux leather upholstery support frequent use in shared co-working environments with multiple rotating users | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Office furniture - Office work chairs - Part 1: Dimensions - determination of dimensions, applicable for validating seat, backrest and clearance dimensions for ergonomic office use | |
|---|---|---|
| EN 1335-2:2018 | Office furniture - Office work chairs - Part 2: Safety requirements, applicable for structural stability, strength and durability testing for commercial use | |
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable for verifying tip resistance during normal use and recline |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Office Chairs - General purpose tests for safety, durability and structural performance, including base load, caster durability, backrest strength and cyclic testing |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | General test standard for furniture: desks and chairs dimensional tolerance requirements, applicable for verifying seat height, depth and clearance specifications | |
|---|---|---|
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural safety and finish durability of inner shell and upholstered components | |
| GB 28007-2011 | Safety of children's furniture (if used in minor-access spaces) requiring anti-tip and load safety compliance, applicable for shared spaces where younger users may access the chair |
This product must meet the following technical requirements: 1. GB/T 3326-2016: General test standard for furniture: desks and chairs dimensional tolerance requirements, applicable for verifying seat height, depth and clearance specifications; 2. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural safety and finish durability of inner shell and upholstered components; 3. GB 28007-2011: Safety of children's furniture (if used in minor-access spaces) requiring anti-tip and load safety compliance, applicable for shared spaces where younger users may access the chair; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
