| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 650 x 660 x 1020 mm | |
|---|---|---|
| Seat width | 490 mm | |
| Seat depth | 470 mm | |
| Seat height range | 520 mm | |
| Backrest height | 540 mm | |
| Backrest width | 480 mm | |
| Armrest height from seat | 210 mm | |
| Five-star base diameter | 640 mm | |
| Caster diameter | 50 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest padding thickness | 60 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net chair weight | 17 kg | |
|---|---|---|
| Maximum user weight capacity | 136 kg | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 35 kg/m³ | |
| Foam rebound rate | 45% | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Caster rolling durability | 50000 cycles | |
| Gas lift cycle life | 120000 cycles | |
| Available upholstery colors | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Upholstery material | 1.0mm thick polyurethane (PU) leather | |
|---|---|---|
| Seat cushion padding | High-density polyurethane foam | |
| Backrest padding | Contoured high-density polyurethane foam | |
| Internal seat/back frame | 12mm thick molded plywood | |
| Five-star base | 2.0mm thick polished chrome-plated steel | |
| Gas lift cylinder | Class 3 chrome-plated steel gas lift | |
| Tilt mechanism | 2.5mm thick black powder-coated steel tilt chassis | |
| Armrest structure | Integrated molded armrests upholstered in matching PU leather | |
| Casters | 50mm diameter nylon twin-wheel casters | |
| Hardware fasteners | Zinc-plated steel bolts and connectors | |
| Edge trim | Matching color fine edge piping | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| 360-degree swivel rotation | Full 360° horizontal rotation enabled by central gas lift bearing, standard for swivel office chairs allowing easy access to surrounding workspace | |
|---|---|---|
| Seat height adjustment | Pneumatic height adjustment via right-side lever, 100mm vertical travel from 420mm to 520mm seat height, accommodating 185 cm user heights | |
| Back tilt function | Synchronized tilt with 12° maximum backward recline, controlled by chassis lever allowing lock in upright position | |
| Tilt tension adjustment | Rotary tension knob under seat adjusts tilt resistance to match user weight 136 kg, preventing too-fast or too-stiff recline | |
| Smooth rolling mobility | Five dual-wheel casters allow omnidirectional movement on hard floors and low-pile carpet without scratching surfaces | |
| Integrated padded arm support | Fixed curved armrests provide continuous forearm support during typing or meetings, 210mm height above seat matching standard desk height | |
| Lumbar support | Contoured mid-back shape provides built-in passive lumbar support aligned with natural spine curve, no adjustable lumbar mechanism | |
| Upright position lock | Chassis lock secures backrest in full upright position for formal conference or task work use | |
| Passive lumbar support | Contoured mid-back shape provides built-in passive lumbar support aligned with the natural seated spine curve, with no adjustable lumbar mechanism | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 680 x 680 x 590 mm | |
| Gross shipping weight | 20 kg | |
| Shipping volume per unit | 0.27 CBM | |
| Required assembly time | 20 minutes | |
| 20ft GP container loading quantity | 240 units | |
| 40ft HQ container loading quantity | 580 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate conference rooms | Formal tailored silhouette and neutral taupe finish suits professional meeting spaces, providing comfortable seating for meetings up to 4 hours duration | |
|---|---|---|
| Executive office task seating | Polished chrome base and smooth PU upholstery complements executive desk setups, supporting daily computer and administrative work | |
| Private office visitor seating | Fixed upright position and integrated armrests provide appropriate formal seating for guests and visitors in private offices | |
| Co-working flexible workspaces | Swivel and height adjustment functions suit flexible shared work areas, neutral finish coordinates with diverse interior design schemes | |
| Hotel business center seating | Durable PU upholstery resists stains and is easy to clean, suitable for high-turnover public business facility use | |
| Healthcare/consulting room seating | Smooth non-porous upholstery allows easy disinfection, comfortable for patient or client consultation seating | |
| Consulting room client seating | Smooth non-porous upholstery allows simple disinfection between users, with contoured support for extended client consultation sessions | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Recommended applicability: Office furniture - Office work chairs - Part 1: Dimensions, determining compliance with minimum ergonomic dimensional requirements for task seating | |
|---|---|---|
| EN 1335-2:2018 | Recommended applicability: Office work chairs - Part 2: Safety requirements, validating structural stability, strength and durability for commercial use | |
| EN 1021-1:2014 | Recommended applicability: Upholstered furniture - Ignition resistance to smouldering cigarette, baseline fire safety requirement for office seating |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1 Test 5 | Recommended applicability: Backrest durability test, 120000 cycles to validate structural integrity of backrest and frame under repeated recline loads |
|---|
Standards applicable to China-market projects
| GB/T 3326-2016 | Recommended applicability: Test method for dimensions of furniture - chairs and stools, validating dimensional consistency with ergonomic requirements for office seating | |
|---|---|---|
| GB/T 35607-2017 | Recommended applicability: Green product assessment standard for furniture, verifying limited formaldehyde and harmful substance content in upholstery and foam | |
| GB 28007-2011 | Recommended applicability: General technical requirements for children's furniture does not apply; this product is rated for adult commercial office use only | |
| GB/T 10357.3-2013 | Recommended acceptance criterion: Test of mechanical properties of furniture - Strength and durability of chairs and stools, validating structural performance for commercial daily use; confirm via supplier test report for tender |
This product must meet the following technical requirements: 1. GB/T 3326-2016: Recommended applicability: Test method for dimensions of furniture - chairs and stools, validating dimensional consistency with ergonomic requirements for office seating; 2. GB/T 35607-2017: Recommended applicability: Green product assessment standard for furniture, verifying limited formaldehyde and harmful substance content in upholstery and foam; 3. GB 28007-2011: Recommended applicability: General technical requirements for children's furniture does not apply; this product is rated for adult commercial office use only; 4. GB/T 10357.3-2013: Recommended acceptance criterion: Test of mechanical properties of furniture - Strength and durability of chairs and stools, validating structural performance for commercial daily use; confirm via supplier test report for tender; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
