Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 680 x 700 x 1180 mm | |
|---|---|---|
| Seat height (adjustable range maximum) | 520 mm | |
| Seat width | 520 mm | |
| Seat depth | 480 mm | |
| Backrest total height | 780 mm | |
| Backrest width at widest point | 500 mm | |
| Integrated headrest height | 220 mm | |
| Armrest height above seat | 200 mm | |
| 5-star base diameter | 660 mm | |
| Caster diameter | 50 mm | |
| Seat pan plywood shell thickness | 15 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 23 kg | |
|---|---|---|
| Maximum static user weight capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Backrest foam density | 35 kg/m³ | |
| Foam rebound rate | 45% | |
| Seat padding thickness | 80 mm | |
| Backrest padding thickness | 60 mm | |
| Caster rolling durability cycle rating | 50000 cycles | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Standard warranty period for commercial use | 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer structural shell | 15mm thick bent laminated plywood with natural zebra wood grain veneer, clear matte lacquer finish | |
|---|---|---|
| Seat upholstery | Black matte fabric or PU leather upholstery over high-density polyurethane foam | |
| Backrest upholstery | Black matte upholstery over medium-density polyurethane foam, integrated into bentwood shell | |
| Integrated armrests | Curved padded armrests matching seat upholstery, mounted directly to bentwood shell | |
| Support column | Polished chrome-plated steel gas lift cylinder, 50mm outer diameter | |
| 5-star base | Polished chrome-plated tubular steel, 1.5mm wall thickness, 5 radial legs | |
| Gas lift class rating | Class 3 commercial grade | |
| Tilt mechanism | 2.5mm thick steel tilt chassis with tension adjustment | |
| Casters | Black nylon twin-wheel hard-floor casters with metal roller bearings | |
| Edge finish | Smooth rounded edge treatment on all bentwood shell edges to prevent sharp contact | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Swivel function | 360-degree continuous rotation around central gas lift axis for full workspace access without standing | |
|---|---|---|
| Seat height adjustment | 100mm vertical height adjustment via gas lift activated by under-seat lever, adjustable between 420mm and 520mm seat height | |
| Backrest tilt function | 12-degree synchronized backward tilt with adjustable tension control to match user body weight, lockable in upright position | |
| Mobility function | Smooth rolling on hard tile, wood or low-pile carpet floors via 5 twin-wheel casters, no fixed glides fitted | |
| Integrated head support | Fixed high-back integrated headrest section positioned to support neck and head during upright work and reclined rest | |
| Integrated arm support | Fixed curved padded armrests positioned to support forearms during typing and desk work, no height or width adjustment | |
| Lumbar support | Contoured backrest shape formed by bentwood shell and padding provides passive lumbar support in the natural lower back curve | |
| Upholstery abrasion resistance | 50000 Martindale cycles minimum, suitable for 8-hour daily commercial office use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit per carton | |
|---|---|---|
| Shipping carton dimensions | 780 x 620 x 580 mm | |
| Gross shipping weight per carton | 27 kg | |
| Shipping volume per unit (CBM) | 0.28 CBM | |
| Required assembly time | 20 minutes | |
| 20ft GP container loading quantity | 105 units | |
| 40ft HQ container loading quantity | 265 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Executive private office use | Suitable for manager and executive private offices, high-back design supports extended sitting during meetings, desk work and decision making | |
|---|---|---|
| Open plan workstation use | Suitable for senior staff open plan workstations, neutral black and wood finish coordinates with most modern office fitouts | |
| Meeting and boardroom use | Suitable for boardroom and formal meeting spaces, uniform styling creates a professional cohesive look around conference tables | |
| Home office use | Suitable for premium home office setups, compact footprint and modern aesthetic complements residential workspaces | |
| Co-working space premium zone use | Suitable for premium dedicated desk zones in co-working facilities, durable construction supports frequent user rotation without rapid wear | |
| Hard floor environment compatibility | Suitable for installation on tile, polished concrete and hardwood floors, standard hard-floor casters prevent floor scuffing | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Applicable office chair safety standard | EN 1335:2018 | |
|---|---|---|
| Applicable upholstery fire resistance standard | EN 1021:2014 |
US and Canada office-furniture standards
| Applicable office chair durability standard | ANSI/BIFMA X2017 | |
|---|---|---|
| Gas lift BIFMA X5.1 cycle rating | 120000 cycles |
Standards applicable to China-market projects
| Applicable stability and safety standard | GB/T 3326 | |
|---|---|---|
| Applicable upholstery formaldehyde limit | GB 18584 |
This product must meet the following technical requirements: 1. Applicable stability and safety standard: GB/T 3326; 2. Applicable upholstery formaldehyde limit: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
