Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 620 x 650 x 980 mm | |
|---|---|---|
| Seat width | 500 mm | |
| Seat depth | 480 mm | |
| Seat height from floor | 450 mm | |
| Backrest height | 520 mm | |
| Backrest width | 470 mm | |
| Armrest height from seat | 200 mm | |
| Chrome star base diameter | 600 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest cushion thickness | 60 mm | |
| Armrest pad length | 250 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 16 kg | |
|---|---|---|
| Maximum static user weight capacity | 136 kg | |
| Recommended daily usage duration | 8 hours | |
| Seat foam density | 45 kg/m³ | |
| Back foam density | 40 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Fabric abrasion resistance (Martindale) | 50000 cycles | |
| Swivel rotation range | 360 degrees | |
| Base static load rating | 1136 kg | |
| Standard warranty period | 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.0mm thick camel brown polyurethane (PU) leather | |
|---|---|---|
| Seat internal support board | 12mm thick multi-layer plywood | |
| Seat padding | High-density cold-cured polyurethane foam | |
| Back padding | Medium-density polyurethane foam with integrated lumbar contour | |
| Armrest padding | Integrated PU-padded armrests matching seat upholstery, mounted on 2mm thick brushed steel support brackets | |
| Swivel base | 2.0mm thick polished chrome-plated four-star cantilever steel frame | |
| Central swivel mechanism | 2.5mm thick steel plate tilt-free return swivel mechanism | |
| Floor contact glides | Hard nylon non-marking glide pads | |
| Frame edge trim | White ABS plastic trim along the bottom edge of seat and back panels | |
| Upholstery stitching | High-strength bonded polyester thread | |
| Armrest pads | Integrated PU-padded pads matching seat upholstery, mounted on 2mm thick brushed steel support brackets | |
| Armrest support finish | Brushed satin chrome finish on steel armrest mounting brackets |
Adjustment / rotation / tilt / mobility / storage features
| Swivel operation | 360-degree free rotation around central vertical axis via precision bearing swivel mechanism, no angle lock positions | |
|---|---|---|
| Height adjustment | Fixed seat height with no gas lift height adjustment, optimized for standard 750mm height conference tables and desks | |
| Tilt function | Fixed upright backrest angle at 100 degrees from seat surface, no recline or tilt tension adjustment, intended for formal upright meeting posture | |
| Armrest function | Fixed-height integrated padded armrests providing forearm support during meetings and writing tasks, no height or width adjustment | |
| Mobility configuration | Stationary glide base with no rolling casters, designed for low-slip placement on hard polished office floors, with optional caster upgrade available | |
| Lumbar support | Contoured fixed lumbar support built into the lower backrest panel, aligned to natural lumbar curve for upright sitting | |
| Color option availability | 3 standard upholstery color options: camel brown, black, dark gray, with custom color matching available for bulk orders | |
| Assembly requirement | Knock-down delivery requiring attachment of base to seat unit, with included hardware and assembly instructions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Number of packages per unit | 1 | |
|---|---|---|
| Single carton dimensions | 670 x 520 x 650 mm | |
| Gross weight per packaged unit | 19 kg | |
| CBM per unit | 0.227 m³ | |
| Assembly time per unit | 20 minutes | |
| 20ft GP container loading quantity | 132 units | |
| 40ft HQ container loading quantity | 330 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Corporate boardrooms and formal meeting rooms | Formal camel PU upholstery and polished chrome trim match professional executive environments, fixed upright posture supports 8 hours of daily meeting use without slouching | |
|---|---|---|
| Executive office guest and visitor seating | Compact footprint and polished chrome trim complement premium executive desk setups for visitor placement across desks | |
| High-end hotel conference and business center spaces | Wear-resistant PU upholstery and stationary glide base suit high-traffic shared meeting spaces with hard flooring | |
| Open plan collaboration zones | 360-degree swivel allows easy turning to engage with group members during collaborative discussions | |
| Training room fixed seating configurations | Fixed height and stationary base allow consistent sight lines in rows of training room seating, with no adjustable parts to distract attendees | |
| Executive lounge and waiting areas | Padded seat and back provide comfortable short-term waiting seating, with camel finish adding warm accent to neutral interior palettes | |
| Executive lounge and premium waiting areas | 80mm thick padded seat and 60mm back padding provide comfortable short-term waiting seating, with warm camel finish adding a refined accent to neutral interior palettes | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Access Requirements* EN Standards
| EN 1335-1:2020 | Office furniture - Office work chairs - Part 1: Dimensions - applies to seat height, seat depth, backrest dimension compatibility with standard European desk heights | |
|---|---|---|
| EN 1335-2:2018 | Office furniture - Office work chairs - Part 2: Safety requirements - applies to structural stability, load capacity and absence of sharp edges | |
| EN 1335-3:2009 | Office furniture - Office work chairs - Part 3: Test methods - specifies structural durability and static load test protocols for procurement acceptance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.1-2017 | Standard for office chairs: applies to static load, backrest strength, base durability and stability testing for general office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard: applicable reference for material content, emissions and end-of-life recyclability for green procurement requirements |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture: applicable to structural strength, dimensional stability and finish quality of internal plywood frame and trim components | |
|---|---|---|
| GB/T 35607-2017 | Limits of harmful substances for upholstered furniture: applicable to formaldehyde and VOC emission limits for foam, upholstery and adhesive components | |
| GB/T 24821-2009 | Office furniture - chairs and stools for office use: applicable to structural stability, load capacity and safety edge requirements |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture: applicable to structural strength, dimensional stability and finish quality of internal plywood frame and trim components; 2. GB/T 35607-2017: Limits of harmful substances for upholstered furniture: applicable to formaldehyde and VOC emission limits for foam, upholstery and adhesive components; 3. GB/T 24821-2009: Office furniture - chairs and stools for office use: applicable to structural stability, load capacity and safety edge requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
