Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 500 × 500 × 610 mm | |
|---|---|---|
| Overall set dimensions (taller table) | 500 x 500 x 610 mm | |
| Shorter table dimensions | 500 x 500 x 510 mm | |
| Tabletop thickness | 12 mm | |
| Taller table pedestal stem diameter | 50 mm | |
| Taller table base footprint diameter | 350 mm | |
| Shorter table base footprint diameter | 320 mm | |
| Nesting overlap depth | 300 mm | |
| Floor clearance under tabletop | 598 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Per-table static load capacity | 100 kg | |
|---|---|---|
| Total set net weight | 16 kg | |
| Tabletop surface scratch resistance | Grade 3 (1500 revolutions) | |
| Base floor contact static stability | 15 degree tilt without tipping | |
| Tabletop heat resistance | 180 °C | |
| Surface water resistance rating | IPX4 | |
| Limited warranty period | 1 year | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 12mm polished sintered stone, grey marble-look finish, non-porous surface | |
|---|---|---|
| Pedestal stem | 2mm thick carbon steel tube, matte black powder coat | |
| Base weight | 2.5mm thick hammered carbon steel, textured hand-beaten black finish | |
| Tabletop-to-base connection | Steel mounting plate with M8 threaded hardware, welded to stem | |
| Floor contact pads | 3mm thick non-slip EVA rubber pads, affixed to base bottom | |
| Surface coating on metal parts | 80μm thick matte black powder coating, rust-resistant for indoor use | |
| Tabletop edge finish | 1mm radius polished eased edge, no raised lip | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Nesting storage function | Shorter table slides partially under taller table to reduce footprint when not in use | |
|---|---|---|
| Floor protection function | EVA rubber pads prevent scuffs and scratches on hard flooring and carpet | |
| Cleaning requirement | Wipe clean with soft damp cloth, no abrasive cleaners required | |
| Assembly requirement | 3-point screw connection between tabletop and base with included hex key | |
| Weight distribution design | Low center of gravity from weighted flared base prevents tipping when loaded | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Bedroom nightstand alternative | Use as paired bedside tables for modern or industrial style bedrooms | |
|---|---|---|
| Lounge and reception accent use | Place in office reception areas or lounge spaces for guest beverage placement | |
| Small space flexible arrangement | Suitable for studio apartments where nesting function saves floor space when not in use | |
| Balcony casual seating area | Use on covered indoor balconies paired with small accent chairs for drinks and reading materials |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
