Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 900 × 350 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Leg diameter | 220 mm | |
| Under-table clearance | 220 mm | |
| Edge radius | 40 mm | |
| Leg center spacing | 600 mm | |
| Maximum tabletop overhang | 300 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Static distributed tabletop load | 90 kg | |
|---|---|---|
| Net product weight | 45 kg | |
| Finish surface hardness | 2H | |
| Impact resistance (edge drop) | 1 kg at 300 mm | |
| Recommended seating area coverage | 3seat sofa | |
| Warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Core table base | Solid kiln-dried hardwood frame | |
|---|---|---|
| Tabletop surface coating | Multi-layer high-gloss UV-cured art lacquer | |
| Painted pattern layer | Hand-applied abstract graffiti art paint | |
| Integrated leg construction | Solid wood core wrapped in continuous matching lacquer | |
| Edge treatment | Fully rounded polished lacquer edge | |
| Finish coating thickness | 0.2 mm | |
| Surface scratch resistance | Class 2 abrasion rating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structural assembly | Fully assembled one-piece construction | |
|---|---|---|
| Mobility feature | No casters or moving parts | |
| Storage provision | No built-in drawers, shelves or compartments | |
| Surface cleaning property | Non-porous glossy finish for wipe-clean maintenance | |
| Safety design | Fully rounded edges and corners to eliminate impact injury risk | |
| Customization option | Support for custom size and pattern per order | |
| Height adjustment | No height or tilt adjustment mechanism | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room center placement | Position in front of 3seat sofas for drinks, decor and reading materials | |
|---|---|---|
| Art-forward residential spaces | Suits eclectic, Memphis, retro or contemporary maximalist interior design schemes | |
| Creative commercial spaces | Ideal for boutique lounges, design studios, gallery waiting areas and themed cafes | |
| Low-seating arrangements | Pairs with floor cushions, modular sofas and lounge chairs at 400 mm seat height | |
| Decorative focal point use | Functions as standalone sculptural accent piece when not in active use | |
| Child-friendly household areas | Rounded edges reduce impact injury risk for family living spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic dining tables, applicable for load testing | |
|---|---|---|
| EN 71-3:2019 | Migration of certain elements for surface coatings, applicable for painted finish safety | |
| EN 15372:2016 | Furniture surface finish resistance to cold liquids for spill resistance verification |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural integrity check | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material limit of harmful substances for wooden furniture | |
| GB/T 4893.4-2013 | Surface furniture film adhesion test method for lacquer finish verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrity check; 2. GB 18584-2001: Indoor decoration material limit of harmful substances for wooden furniture; 3. GB/T 4893.4-2013: Surface furniture film adhesion test method for lacquer finish verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
