Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1680 x 450 x 890 mm | |
|---|---|---|
| top surface raised lip height | 80 mm | |
| drawer front height | 180 mm | |
| individual drawer internal dimensions | 520 x 380 x 120 mm | |
| glass door compartment internal width | 480 mm | |
| internal shelf depth behind glass doors | 390 mm | |
| shelf height adjustment increment | 32 mm | |
| solid right door compartment width | 520 mm | |
| plinth base height | 80 mm | |
| top surface usable depth | 420 mm | |
| tempered glass door panel thickness | 4 mm | |
| main cabinet panel thickness | 15 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| assembled product weight | 73 kg | |
|---|---|---|
| top surface static load capacity | 91 kg | |
| recommended storage capacity per glass compartment | 42 L | |
| solid door compartment storage capacity | 88 L | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| cabinet carcass | 15mm P2 grade engineered wood (MDF/particleboard) with light wood-grain melamine laminate | |
|---|---|---|
| drawer fronts and side end panels | Pale sage scratch-resistant matte painted MDF | |
| lower cabinet doors (left and middle) | Semi-transparent 4mm tempered safety glass set in wood-grain laminate frames | |
| right lower cabinet door | Light wood-grain melamine faced MDF matching cabinet body finish | |
| drawer and door pulls | Brushed dark grey steel vertical/horizontal bar handles | |
| internal adjustable shelves | 15mm melamine faced engineered wood with 0.5mm PVC edge banding | |
| drawer slides | Side-mounted steel roller glides with integrated safety stops | |
| door hinges | Concealed steel soft-close hinges with 110-degree opening angle | |
| back panel | 3mm hardboard with melamine backing for structural stability | |
| plinth base | 15mm engineered wood finished to match cabinet body | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| top raised lip edge | Curved integrated lip along back and right edges to prevent small items from sliding off | |
|---|---|---|
| upper drawer operation | Two equal-size drawers on steel roller glides, full 3/4 extension for access to stored cutlery or linens | |
| glass door storage | Two doors with one position-adjustable shelf each for display and concealed storage of dishware | |
| solid door storage | Full-height single door compartment with fixed base for concealed storage of larger serving items | |
| door hinge function | Soft-close hinges prevent slamming, open 110 degrees for unobstructed interior access | |
| leveling adjustment | Concealed adjustable feet under plinth for fine leveling on uneven floor surfaces | |
| surface performance | Melamine and matte painted surfaces are water-repellent and wipe-clean for dining area use | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| dining room application | Positioned against a wall as a buffet for storing table linens, dishware, and serving pieces | |
|---|---|---|
| living room application | Used as a low credenza below wall-mounted art or a television for media accessory storage | |
| entryway application | Placed in a foyer to store entry essentials and display decorative objects on the raised-lip top | |
| target user group | Residential and small commercial spaces seeking modern two-tone enclosed storage with display capacity | |
| recommended pairing | Matches light oak and soft neutral furniture palettes with slat wall paneling and light flooring | |
| clearance requirement | Requires 100mm clearance in front of doors for full opening and access to stored items |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and performance requirements for domestic storage furniture, applicable for stability testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional and structuralAcceptance |
|---|
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional and structuralAcceptance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
