Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 400 x 900 mm | |
|---|---|---|
| Open upper shelf internal dimensions | 760 x 360 x 250 mm | |
| Lower double-door compartment internal dimensions | 760 x 360 x 570 mm | |
| Interior adjustable shelf thickness | 35 mm | |
| Main body panel thickness | 15 mm | |
| Back panel thickness | 3 mm | |
| Door panel thickness | 15 mm | |
| Edge banding thickness | 2 mm | |
| Leveling foot height adjustment range | 15 mm | |
| Open shelf clearance above shelf surface | 240 mm | |
| Door hinge opening angle | 110 degrees | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Total cabinet static load capacity | 91 kg | |
|---|---|---|
| Product net weight | 29 kg | |
| Hinge cycle durability | 50000 open/close cycles | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Lock mechanism cycle durability | 10000 lock/unlock cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass panels | 15mm double-sided white melamine laminated MDF | |
|---|---|---|
| Back panel | 3mm hardboard with white finish | |
| Door panels | 15mm white melamine laminated MDF, flush fit | |
| Edge banding | 2mm white PVC edging on all exposed panel edges | |
| Lock mechanism | Zinc alloy combination/key cylinder lock | |
| Hinges | Cold-rolled steel concealed hinges with nickel plating | |
| Leveling feet | Nylon base with steel threaded shank | |
| Interior shelf | 15mm white melamine laminated MDF, height adjustable | |
| Top surface | 15mm white melamine laminated MDF with rounded front edge | |
| Surface finish | Scratch-resistant, stain-resistant matte white melamine | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| Upper open shelf storage | Full-width open compartment for frequently accessed items and display | |
|---|---|---|
| Lower lockable storage | Double-door enclosed compartment secured by integrated lock | |
| Interior shelf adjustment | One adjustable shelf with 3 height positions | |
| Door operation | Double hinged swing doors opening 110 degrees | |
| Floor leveling | Four threaded adjustable feet at base corners | |
| Lock operation | Single lock secures both lower doors simultaneously | |
| Surface maintenance | Wipe-clean melamine surface | |
| Anti-tip safety | Included wall anchor connector | |
| Lock position from left door edge | 120 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open-plan office workstation side storage | Fits beside desks for file and supply storage | |
|---|---|---|
| Home office document storage | Compact footprint fits small home workspaces | |
| Reception area display and storage | Open shelf shows decor, lower doors hide clutter | |
| Break room supply storage | Stores pantry supplies and office consumables | |
| Small meeting room accessory storage | Holds meeting supplies, notepads and presentation materials | |
| Configuration recommendation | Place against wall, secure with included anti-tip anchor |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office furniture - Storage furniture - Safety requirements | |
|---|---|---|
| EN 14073-3:2004 | Office furniture - Storage furniture - Test methods for stability and strength | |
| EN 13722:2004 | Furniture - Test methods for the assessment of surface resistance |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage Furniture - Tests for safety, durability and structural performance |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture; 2. GB/T 4897.3-2003: Particleboard for furniture use; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
