Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1000 x 400 x 910 mm | |
|---|---|---|
| top guard rail height | 80 mm | |
| upper drawer internal dimensions | 430 x 350 x 120 mm | |
| lower glass door compartment width per unit | 460 mm | |
| fixed interior shelf height from compartment floor | 320 mm | |
| plinth base height | 100 mm | |
| drawer front panel thickness | 18 mm | |
| glass door panel thickness | 5 mm | |
| carcass side panel thickness | 18 mm | |
| interior shelf thickness | 15 mm | |
| back panel thickness | 3 mm | |
| edge banding thickness | 1 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| product net weight | 30 kg | |
|---|---|---|
| top surface static load capacity | 91 kg | |
| hinge open angle | 110 degrees | |
| drawer slide cycle rating | 50000 cycles | |
| hinge cycle rating | 80000 cycles | |
| recommended user weight capacity for top surface | Do not exceed 91 kg evenly distributed | |
| surface scratch resistance rating | 2B | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| cabinet carcass | E1 grade engineered wood with light bleached oak melamine finish | |
|---|---|---|
| upper drawer fronts | MDF panel with matte mint green water-based paint finish | |
| lower door panels | Engineered wood frame with 5mm frosted tempered glass inserts | |
| drawer and door pulls | Brushed silver aluminum alloy bar handles | |
| drawer slides | Cold-rolled steel side-mount 3-section extension slides | |
| door hinges | Cold-rolled steel concealed cup hinges with optional soft-close buffer | |
| interior shelves | Engineered wood with matching light oak melamine finish | |
| plinth base | Engineered wood with matching light oak finish, floor protection pads | |
| back panel | 3mm hardboard with light wood print finish | |
| top guard rail | Engineered wood with matching light oak finish, rounded edge corners | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints |
Adjustment / rotation / tilt / mobility / storage features
| top guard rail function | Three-sided raised lip prevents small items from sliding off back and side edges | |
|---|---|---|
| upper drawer operation | Two independently operable horizontal drawers for small flatware, napkins and table linen storage | |
| lower cabinet storage | Two glass-paneled doors enclose two compartments with fixed mid-height shelves for display and enclosed storage | |
| door access feature | Dual side-hinged doors open to full interior compartment access without blocking adjacent walkways | |
| wall anti-tip function | 1 included steel anti-tip anchor secures cabinet to wall to prevent forward tipping | |
| surface maintenance feature | Melamine and painted surfaces wipe clean with damp cloth, resistant to common household water spills | |
| floor protection function | Felt pads on plinth base corners prevent scratching hard flooring surfaces | |
| display function | Frosted glass panels obscure stored items while allowing partial visibility of displayed dishware | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| dining room use | Position against wall as buffet storage for tableware, linens and serving accessories, top surface holds condiment sets and decor | |
|---|---|---|
| kitchen pantry use | Placed in kitchen as supplementary dry goods and small appliance storage, raised lip prevents items falling during use | |
| living room use | Used as low display cabinet for books, decor and media accessories in open-plan living spaces | |
| entryway use | Positioned in entry foyers for key, mail and entry item storage, top surface holds small decorative pieces | |
| target user group | Suitable for small households and studio apartments requiring compact multi-function enclosed storage | |
| recommended placement clearance | Maintain 100mm clearance from wall for anti-tip anchor installation and door operation | |
| surface use guidance | Flat top surface supports small decor items, stacked books and table serving pieces up to rated load |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Applies to safety and structural requirements for domestic kitchen and dining storage cabinets | |
|---|---|---|
| EN 12150-1:2015 | Applies to thermally toughened soda lime silicate safety glass used in door panels | |
| EN 312:2010 | Applies to particleboard performance requirements for load-bearing furniture applications |
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden residential furniture, including dimensional stability and finish performance | |
|---|---|---|
| GB 18584-2001 | Applies to formaldehyde emission limits for interior wood-based furniture, E1 grade ≤0.124mg/m³ for indoor use | |
| GB/T 4897.3-2003 | Applies to particleboard (PB) used in furniture construction for structural strength requirements | |
| GB/T 15102-2017 | Applies to melamine faced boards used for furniture surfaces for wear and scratch resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden residential furniture, including dimensional stability and finish performance; 2. GB 18584-2001: Applies to formaldehyde emission limits for interior wood-based furniture, E1 grade ≤0.124mg/m³ for indoor use; 3. GB/T 4897.3-2003: Applies to particleboard (PB) used in furniture construction for structural strength requirements; 4. GB/T 15102-2017: Applies to melamine faced boards used for furniture surfaces for wear and scratch resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
