Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 400 x 800 mm | |
|---|---|---|
| Single door panel width | 390 mm | |
| Recessed handle length | 120 mm | |
| Interior adjustable shelf width | 760 mm | |
| Interior shelf depth | 360 mm | |
| Dark top/plinth trim height | 40 mm | |
| Internal clear storage height | 720 mm | |
| Central stile width | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 35 kg | |
|---|---|---|
| Static shelf load capacity | 30 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Drawer slide (if fitted) load rating | 25 kg | |
| Door hinge opening angle | 110 degrees | |
| Recommended user capacity | 1 person per access side | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main cabinet body panels | 18mm E1-grade particleboard with light wood-grain melamine facing | |
|---|---|---|
| Top and plinth trim | 2mm dark grey PVC edge banding and laminated trim | |
| Door panels | 18mm melamine-faced engineered wood with recessed integrated pulls | |
| Back panel | 5mm hardboard with melamine backing | |
| Adjustable shelves | 18mm melamine-faced particleboard with metal shelf pins | |
| Locking mechanism | Zinc alloy central key lock with 2 included keys | |
| Door hinges | Cold-rolled steel soft-close concealed hinges | |
| Edge banding | 1mm PVC edge sealing on all exposed panel edges | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Central key locking | Single-point key lock secures both doors simultaneously, 2 keys provided | |
|---|---|---|
| Recessed handle operation | Flush horizontal recessed pulls on upper door section eliminate protrusions | |
| Adjustable shelf storage | One internal shelf supports 3 height positions at 150mm increments | |
| Plinth base support | Integral dark plinth raises cabinet 40mm above floor for cleaning access | |
| Wall anti-tip anchoring | Included metal anti-tip bracket secures cabinet to wall to prevent tipping | |
| Smooth surface maintenance | Melamine finish resists common office stains and wipes clean with dry cloth | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open-plan office workstation zones | Position under desks or alongside workstations for close supply and file storage | |
|---|---|---|
| Executive and private offices | Place beside desks for locked document and personal item storage | |
| Reception and admin areas | Store office supplies, forms, and reception materials out of sight | |
| Small meeting and break rooms | Store meeting supplies, refreshment items, and presentation materials | |
| Home office spaces | Compact footprint fits home workspaces for locked document and supply storage |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to structural stability | |
|---|---|---|
| EN 14074-2:004 | Office storage furniture test methods for strength and durability | |
| EN 13986:2004 | Wood-based panels for construction and furniture, panel performance requirements |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to wood-based cabinet panels | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to main body panel material | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade requirement |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to wood-based cabinet panels; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to main body panel material; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade requirement; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
