Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 800 x 400 x 1200 mm | |
|---|---|---|
| Upper open shelf compartment height | 320 mm | |
| Open shelf interior depth | 370 mm | |
| Lower double-door compartment height | 840 mm | |
| Single door panel width | 392 mm | |
| Door panel thickness | 18 mm | |
| Adjustable interior shelf thickness (lower cabinet) | 16 mm | |
| Leveling foot height adjustment range | 15 mm | |
| Lower cabinet internal clear width | 768 mm | |
| Open shelf back panel thickness | 9 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Product net weight | 38 kg | |
|---|---|---|
| Static load per shelf (upper open and lower adjustable) | 65 kg | |
| Total static load capacity | 260 kg | |
| Recommended maximum stored binder count | 24 | |
| Door hinge cycle rating | 80000 open/close cycles | |
| Edge band peel strength | 1.2 N/mm | |
| Laminate surface abrasion resistance | 350 cycles | |
| Leveling foot max load per foot | 80 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass panels | 16mm E1 grade particleboard with walnut wood-grain melamine laminate | |
|---|---|---|
| Upper open shelf interior back | 9mm dark brown melamine hardboard | |
| Door panels | 18mm E1 grade particleboard with matching walnut wood-grain laminate | |
| Interior adjustable shelves | 16mm melamine-faced particleboard with anti-slip edge finish | |
| Edge banding | 1mm PVC edge banding on all exposed panel edges | |
| Lock mechanism | Zinc alloy 3-digit combination lock with plastic escutcheon | |
| Door hinges | Cold-rolled steel concealed self-closing hinges with nickel plating | |
| Leveling feet | Reinforced nylon with steel threaded insert, black finish | |
| Back panel fasteners | Zinc-plated steel screws securing back panel to carcass | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Upper open shelf storage | Fixed open compartment for frequently accessed items, decor and reference materials | |
|---|---|---|
| Lower door locking | Single combination lock secures both double doors for confidential document storage | |
| Adjustable lower shelf positions | 5 shelf height positions with 32mm increments for flexible storage of binders and supplies | |
| Door opening angle | 110 degrees per door for full access to lower compartment contents | |
| Floor leveling adjustment | Rotating feet compensate for up to 15mm of uneven floor to keep cabinet plumb | |
| Door alignment | Integrated hinge adjustment screws allow 3mm side/height/ depth tuning for even door gaps | |
| Anti-tip anchoring | Wall anchor bracket included to prevent forward tipping when fully loaded | |
| Lock cylinder protrusion from door face | 12 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Private office space | Placed against wall adjacent to desk for locked document and open supply storage | |
|---|---|---|
| Open plan office area | Used as team storage for shared supplies, reference materials and decor | |
| Home office setup | Provides secure storage for work documents and display for personal items | |
| Reception back-of-house area | Stores office supplies, visitor materials and small equipment | |
| Small meeting room | Holds presentation materials, meeting supplies and decorative plants | |
| Recommended pairing | Matched with walnut-grain executive desks and office seating for cohesive workspace design |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to stability and load capacity | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture stability and strength test methods, applicable to shelf and door performance | |
| EN 16121:2013 | Non-domestic storage furniture safety, strength and durability requirements for commercial use |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture finishes, applicable to melamine surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required for indoor office use; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture finishes, applicable to melamine surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
