Automatic mm / inch conversion · Core engineering specifications
| overall assembled dimensions | 1651 x 559 x 813 mm | |
|---|---|---|
| upper left open shelf compartment | 760 x 350 x 250 mm | |
| upper right open shelf compartment | 830 x 400 x 320 mm | |
| lower right middle open shelf | 420 x 350 x 200 mm | |
| lower right bottom open shelf | 420 x 350 x 250 mm | |
| enclosed door section width | 1100 mm | |
| main carcass panel thickness | 25 mm | |
| back panel thickness | 9 mm | |
| door panel thickness | 18 mm | |
| edge band thickness | 3 mm | |
| base clearance height | 20 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| assembled unit net weight | 54 kg | |
|---|---|---|
| static load per open shelf | 25 kg | |
| static load per enclosed interior shelf | 30 kg | |
| top surface static load | 40 kg | |
| door hinge cycle rating | 80000 open/close cycles | |
| finish abrasion resistance | 40000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| main carcass construction | E1 grade engineered MDF/particle board core | |
|---|---|---|
| carcass surface finish | Dark charcoal matte thermal-fused melamine laminate | |
| door front panels | Brown engineered wood with diagonal raised textured finish | |
| door header trim | Vertical dark fluted/reeded decorative panel | |
| interior shelves | 25mm thick melamine laminated engineered wood | |
| edge banding | 3mm thick matching dark PVC edge trim | |
| door hinges | Cold-rolled steel concealed soft-close hinges | |
| anti-tip hardware | Included steel wall anchor bracket | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| enclosed storage access | Three hinged doors open 110 degrees to reveal concealed interior shelving | |
|---|---|---|
| interior shelf adjustment | Enclosed compartment shelves adjust to 3 fixed height positions | |
| open display storage | Three tiered stepped open shelves for books, decor and frequently accessed items | |
| placement flexibility | Suitable for freestanding floor placement or wall-mounted installation | |
| anti-tip safety | Wall anchoring kit prevents forward tipping during full load or door operation | |
| door operation | Soft-close hinge mechanism prevents slamming during door closure | |
| storage capacity | Combined 180L total storage volume across open and enclosed compartments | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| executive office side placement | Position against office wall adjacent to desks for document and decor storage | |
|---|---|---|
| modern open office breakout space | Store books, decor and supplies in collaborative open work areas | |
| manager private office backdrop | Use as low credenza behind seating for display and concealed storage | |
| home office storage | Suitable for premium home office environments with mixed storage needs | |
| reception area display storage | Place in reception zones to showcase branding items and store supplies |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture | |
|---|---|---|
| EN 14073-2:2004 | Office storage furniture safety requirements for commercial workplace use |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Performance standard for office storage units, applicable for commercial installations |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to this storage cabinet | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor use |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to this storage cabinet; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade requirement for indoor use; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
