PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	600 × 400 × 800 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended total static load	40 kg
Top surface load	20 kg
Fixed open shelf load	10 kg per shelf
Enclosed interior shelf load	15 kg per shelf
Cabinet net weight	28 kg
Recommended binder capacity	18 standard binders
Door cycle rating	50,000 open/close cycles
Warranty target	3 years
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main cabinet panels	18 mm melamine-faced wood-based panel with sealed exposed edges
Door fronts	Light oak-color melamine panels with vertical fluted surface texture
Interior surfaces	Smooth medium-gray melamine or laminate-lined shelf and back surfaces
Top panel	Light oak-color wood-based panel with a subtle projecting edge
Back panel	9 mm wood-fiber or hardboard back panel set into a recessed frame
Support legs	Four matte dark-gray rigid legs, likely plastic or painted composite

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Storage layout	Upper section provides one tall open bay and two stacked open shelves; lower section provides two enclosed door bays.
Door operation	Two front doors swing outward on 110-degree concealed hinges and provide access to separate lower compartments.
Interior shelf adjustment	Each enclosed bay accepts one adjustable shelf at five 32 mm height positions.
Open shelf use	The 325 mm left bay holds upright binders or books; the two 160 mm right shelves hold documents and trays.

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office and administrative space	Suitable beside a workstation or in a copy area for binders, documents, printers, and frequently used supplies.
Home study or living storage	Fits a study, entry, or living area where open display and concealed clutter storage are both required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · LSC-600-400-800-2D

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · LSC-600-400-800-2D

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · LSC-600-400-800-2DOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Door Low Storage Cabinet with Open Shelves combines a low, freestanding profile with a balanced storage layout suited to both working and living environments. Its upper section presents one tall open bay beside two stacked open shelves, while the lower section is divided into two enclosed door bays. The light oak-color melamine surfaces and vertically fluted door fronts give the cabinet a textured contemporary appearance, complemented by smooth medium-gray interior linings, a subtly projecting top edge, and four matte dark-gray support legs. The cabinet is built from wood-based panels with a melamine finish. Main cabinet panels are 18 mm melamine-faced board with sealed exposed edges, while the stated carcass and shelf thickness is 25 mm, the door fronts are 22 mm, and the back panel is 9 mm. The wood-fiber or hardboard back is set into a recessed frame, and the doors operate on concealed hinges with a 110-degree outward swing. Each lower compartment accepts one adjustable shelf with five 32 mm height positions, allowing users to adapt enclosed storage to different file or supply sizes. Functionally, the open left bay supports upright binders or books, while the two narrower right-hand shelves are arranged for documents and trays. Behind the fluted doors, two separate lower compartments conceal items that are preferred out of view. The design is rated for a recommended total static load of 40 kg, with a 20 kg top surface load, a 10 kg load per fixed open shelf, and a 15 kg load per enclosed interior shelf. Its reference binder capacity is 18 standard binders, and the door hardware carries a 50,000 open/close cycle rating. This cabinet works well beside a workstation or in a copy area for binders, documents, printers, and frequently used office supplies. It is also appropriate for a home study, entry area, or living space where visible display and concealed storage are both required.

Two-Door Low Storage Cabinet with Open Shelves Specifications
