Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 400 x 1600 mm | |
|---|---|---|
| Floor clearance under cabinet base | 100 mm | |
| Top open compartment height | 300 mm | |
| Top open compartment width (each divided section) | 790 mm | |
| Middle open compartment internal height | 900 mm | |
| Middle open shelf clearance per tier | 280 mm | |
| Sliding door panel dimensions (each) | 790 x 1200 mm | |
| Door overlap gap between sliding panels | 30 mm | |
| Back panel thickness | 3 mm | |
| Main carcass panel thickness | 18 mm | |
| Shelf panel thickness | 18 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Static load per adjustable/fixed shelf | 25 kg | |
|---|---|---|
| Total cabinet static load capacity | 150 kg | |
| Top open shelf surface static load | 25 kg | |
| Sliding door track cycle life | 20000 open/close cycles | |
| Unit net weight | 65 kg | |
| Anti-tip hardware rated pull-out resistance | 50 kg | |
| Surface abrasion resistance (laminate finish) | 300 revolutions | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass and door panels | 18mm melamine-faced particle board (MFC) with light oak vertical wood grain | |
|---|---|---|
| Back panel | 3mm hardboard (HDF) with matching light neutral finish | |
| Horizontal and vertical shelf dividers | 18mm matching melamine-faced MFC fixed with cam-lock hardware | |
| Sliding door track system | Powder-coated galvanized steel top and bottom tracks with plastic glide inserts | |
| Support feet | Injection-molded polypropylene square block feet in light neutral finish | |
| Edge banding | 0.8mm PVC edge banding matching wood grain finish on all exposed panel edges | |
| Assembly hardware | Zinc-plated steel cam locks, wood dowels and screw fasteners | |
| Anti-tip kit | Steel wall anchor bracket with steel mounting screw and plastic wall plug | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Sliding door operation | Two solid panels slide horizontally along top and bottom tracks to access lower storage, no outward door swing for tight space use | |
|---|---|---|
| Open display storage | Two top divided compartments and three middle open tiers provide visible storage for decor and frequently accessed items | |
| Concealed storage access | Sliding doors cover two separate enclosed lower compartments when closed, concealing stored items for a neat appearance | |
| Fixed shelf structure | All visible open shelves are fixed in place for consistent structural rigidity, no shelf position adjustment | |
| Floor protection function | Raised plastic feet elevate cabinet base to prevent moisture damage from floor contact and simplify floor cleaning | |
| Dust protection for closed storage | Overlapping sliding doors form a continuous closed front to reduce dust accumulation on stored items in covered compartments | |
| Wall anchoring function | Included anti-tip hardware secures cabinet to wall to prevent forward tipping during loading or door operation | |
| Support foot block dimensions | 40 x 40 x 100 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Residential living room use | Placed against a wall to store media accessories, books and display decor, sliding doors save space in narrow rooms | |
|---|---|---|
| Home office storage use | Positioned beside a desk to store files, office supplies and reference materials, open shelves hold frequently accessed items | |
| Entryway/mudroom use | Located near entry doors to store shoes, bags and daily essentials, concealed compartments hide clutter from view | |
| Dining room sideboard use | Used to store tableware, linens and serving pieces, top open shelves display decorative table accessories | |
| Bedroom storage use | Placed in a bedroom to store folded clothing, linens and personal items, neutral light finish complements modern bedroom decor |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and kitchen storage furniture, applicable for structural performance validation | |
|---|---|---|
| EN 312:2010 | Particle board performance specification, applicable for verifying panel suitability for furniture construction | |
| EN 12521:2015 | Strength, durability and safety requirements for domestic furniture storage units, applicable for load testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for dimensional tolerance, surface quality and structural strength checks | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable for E1 grade emission verification for indoor use | |
| GB/T 4897.3-2015 | Particle board for furniture use, applicable for verifying structural panel quality |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for dimensional tolerance, surface quality and structural strength checks; 2. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable for E1 grade emission verification for indoor use; 3. GB/T 4897.3-2015: Particle board for furniture use, applicable for verifying structural panel quality; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
