Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 900 x 400 x 900 mm | |
|---|---|---|
| Support foot height | 30 mm | |
| Single door width | 440 mm | |
| Door thickness | 20 mm | |
| Carcass side panel thickness | 0.6 mm | |
| Back panel thickness | 0.4 mm | |
| Adjustable shelf thickness | 0.8 mm | |
| Top surface thickness | 25 mm | |
| Interior storage height | 820 mm | |
| Edge band thickness | 1 mm | |
| Adjustable shelf height increment | 32 mm | |
| Door opening clearance width | 860 mm | |
| Carcass Panel Thickness | 25 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Unit net weight | 25 kg | |
|---|---|---|
| Per-shelf static load capacity | 80 kg | |
| Hinge open/close cycle rating | 80000 cycles | |
| Drawer slide load rating (per shelf equivalent) | 80 kg | |
| Recommended maximum stored item weight per door | 10 kg | |
| Anti-tip connector load rating | 100 kg | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass body | 0.6mm thick cold-rolled steel sheet | |
|---|---|---|
| Door panels | 0.6mm thick cold-rolled steel with double-wall reinforcement | |
| Surface finish | Electrostatic epoxy powder coating, light gray matte | |
| Support feet | Zinc-plated steel fixed/levelling feet | |
| Lock mechanism | Zinc alloy electronic combination lock with key override | |
| Hinges | Stainless steel pivot hinges | |
| Interior shelves | 0.8mm thick cold-rolled steel, adjustable | |
| Edge treatment | Rounded safety edges with 1mm powder-coated trim | |
| Back panel | 0.4mm thick cold-rolled steel sheet | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Door operation | Double swing doors opening 110 degrees outward | |
|---|---|---|
| Locking function | Central 2-point locking system securing both doors | |
| Shelf adjustment | 2 height-adjustable interior shelves creating 3 storage zones | |
| Levelling function | Adjustable support feet compensate for uneven floor surfaces | |
| Storage versatility | Interior accommodates A4 folders, office supplies, and small equipment | |
| Anti-tip safety | Included wall anchor prevents forward tipping when loaded | |
| Door alignment | Concealed hinges allow minor door alignment adjustment during assembly | |
| Surface resistance | Powder-coated finish resists fingerprints, stains, and minor abrasions | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office side storage | Placed alongside workstations to store documents, supplies, and personal items | |
|---|---|---|
| Under-counter workspace storage | Positioned under elevated work surfaces for accessible, lockable storage | |
| Home office storage | Used in residential workspaces to secure office materials and reduce clutter | |
| Reception area storage | Placed behind reception desks to store forms, supplies, and visitor materials | |
| Small equipment storage | Stores small office electronics, cables, and accessories on adjustable shelves | |
| Break room storage | Used to store disposable supplies, cleaning materials, and non-perishable items |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements | |
|---|---|---|
| EN 14074:2004 | Office storage furniture test methods for strength and durability |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage Furniture standard for office use |
|---|
Standards applicable to China-market projects
| GB/T 3327-2017 | Metal office furniture general technical requirements | |
|---|---|---|
| GB/T 13668-2015 | Steel filing cabinets for office use | |
| GB 18584-2001 | Indoor decorating and refurbishing materials limit of harmful substances |
This product must meet the following technical requirements: 1. GB/T 3327-2017: Metal office furniture general technical requirements; 2. GB/T 13668-2015: Steel filing cabinets for office use; 3. GB 18584-2001: Indoor decorating and refurbishing materials limit of harmful substances; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
