Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2400 x 500 x 880 mm | |
|---|---|---|
| Countertop thickness | 25 mm | |
| Central open shelf internal dimensions | 600 x 450 x 350 mm | |
| Single cabinet door width | 300 mm | |
| Internal shelf depth (closed cabinets) | 460 mm | |
| Leveler foot height adjustment range | 15 mm | |
| Base plinth height | 50 mm | |
| Open shelf countertop overhang | 10 mm | |
| Carcass Panel Thickness | 25 mm | |
| Back Panel Thickness | 9 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Static load capacity per internal shelf | 15 kg | |
|---|---|---|
| Net weight | 75 kg | |
| Warranty period | 10 years | |
| Laminate surface scratch resistance | 2000 cycles | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Angle / Life | 165°; 80000 cycles | |
| Anti-tip Fixing Reference | Products above 1200 mm should use at least 2 wall fixing points | |
| Recommended Procurement Warranty | Carcass 5 years; hardware 3 years; finish 2 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Cabinet body panels | 18 mm E1 grade particleboard with matte taupe laminate finish | |
|---|---|---|
| Top surface | 25 mm MDF core with light oak effect scratch-resistant laminate | |
| Internal cabinet shelves | 15 mm thick E1 grade particleboard with matching taupe laminate | |
| Door combination locks | Zinc alloy housing with 3-digit resettable combination mechanism | |
| Adjustable leveler feet | M12 carbon steel with chrome-plated base pad | |
| Door hinges | Concealed steel soft-close hinges with 110 degree opening angle | |
| Edge banding | 1 mm thick PVC edge banding on all exposed panel edges | |
| Open shelf back panel | 5 mm thick hardboard with taupe finish | |
| Edge Band Thickness | 2 mm | |
| Primary Connector Specification | Reference M6-M8 cam/bolt fittings with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Lockable storage compartments | 3 individual cabinet sections with integrated combination locks for secure document storage | |
|---|---|---|
| Central open storage cubby | Open recessed shelf sized for frequently accessed binders and office supplies, no door required | |
| Adjustable internal shelves | 2 height positions per closed cabinet for flexible storage of varying document sizes | |
| Floor leveling adjustment | 6 individual adjustable feet to compensate for uneven office flooring | |
| Door opening mechanism | Push-to-open style cabinet doors with no external handles for seamless minimalist aesthetic | |
| Load-rated top surface | Flat continuous work surface suitable for placing printers, decor, or frequently used items | |
| Wall anchor compatibility | Pre-drilled rear mounting points to secure unit to wall for anti-tip safety | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Carton dimensions | 2500 x 600 x 200 mm | |
|---|---|---|
| Gross packaged weight | 85 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Office open plan spaces | Low height form suitable for placement along partition walls without blocking sightlines | |
|---|---|---|
| Executive and private offices | Lockable storage for confidential documents alongside open shelf for daily use materials | |
| Reception and waiting areas | Minimalist aesthetic matches contemporary office design for supply and brochure storage | |
| Meeting and conference rooms | Provides storage for meeting materials, presentation supplies, and room amenities | |
| Home office environments | Scaled size fits residential workspaces for document and home office supply organization | |
| Recommended pairing | Position against solid wall, pair with matching office desk systems for coordinated workspace |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to structural stability and load testing | |
|---|---|---|
| EN 14074:2004 | Office storage furniture test methods, applicable to durability and mechanical performance verification | |
| EN 13986:2004+A1:2015 | Wood-based panels for construction and furniture, applicable to panel material specification | |
| EN 71-3:2019+A1:2021 | Migration of certain elements, applicable to surface finish safety for indoor furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture safety and performance standard for commercial office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable to material and emission performance verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural and finish quality testing | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable to core board material performance verification | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture safety | |
| GB/T 10357.5-2011 | Furniture mechanical performance test for storage units, applicable to shelf and structure load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural and finish quality testing; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable to core board material performance verification; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture safety; 4. GB/T 10357.5-2011: Furniture mechanical performance test for storage units, applicable to shelf and structure load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
