Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1200 x 400 x 650 mm | |
|---|---|---|
| Top surface usable area | 1180 x 380 mm | |
| Internal storage compartment height | 570 mm | |
| Adjustable shelf height intervals | 32 mm | |
| Caster diameter | 60 mm | |
| Edge band thickness | 2 mm | |
| Carcass panel thickness | 18 mm | |
| Door panel thickness | 16 mm | |
| Shelf panel thickness | 18 mm | |
| Back panel thickness | 5 mm | |
| Caster mounting height | 20 mm | |
| Door / Drawer Front Thickness | 22 mm | |
| Shelf Thickness | 25 mm |
Net weight / load capacity / users / durability
| Product net weight | 42 kg | |
|---|---|---|
| Top surface static load capacity | 70 kg | |
| Per-caster load rating | 35 kg | |
| Hinge cycle rating | 50000 open/close cycles | |
| Drawer slide load rating (if equipped) | 30 kg | |
| Recommended maximum number of users | 20 | |
| Surface scratch resistance | 2000 cycles | |
| Warranty period | 3 years | |
| Shelf Distributed Load | 30 kg/shelf | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Carcass panels | E1-grade engineered wood with thermally fused laminate finish | |
|---|---|---|
| Top surface | Walnut-effect laminate over 18mm particleboard core | |
| Access door panel | Beige laminate over 16mm MDF core | |
| Edge banding | 2mm PVC matching walnut wood tone | |
| Back panel | 5mm hardboard with matte finish | |
| Combination lock | Zinc alloy housing with chrome finish | |
| Lock mechanism | Steel cam lock for 1-point latching | |
| Casters | Nylon wheel with steel swivel stem | |
| Brake casters | 2 front lockable casters with rubber brake pad | |
| Door hinges | Cold-rolled steel concealed hinges | |
| Shelf pins | Nickel-plated steel shelf supports | |
| Internal shelf | 18mm particleboard with matching laminate finish |
Adjustment / rotation / tilt / mobility / storage features
| Mobility function | 4 swivel casters (2 lockable) for easy repositioning | |
|---|---|---|
| Security function | 3-digit combination lock secures single access door | |
| Storage configurability | 1 adjustable internal shelf divides compartment into 2 zones | |
| Door operation | Concealed hinges allow 110-degree door swing for full access | |
| Top surface function | Flat finished top supports office equipment such as printers | |
| Anti-tip safety | Wall anchor kit included for securing to drywall or masonry | |
| Edge protection | 2mm PVC edge banding prevents chipping from frequent contact | |
| Surface protection | Scratch-resistant laminate resists daily office wear and spills | |
| Optional drawer fitment | 1 lower full-width drawer compatible with A4/letter hanging files | |
| Soft-close mechanism (if specified) | Hydraulic soft-close door damper reduces closing noise | |
| Combination lock mounting diameter | 60 mm | |
| Cable / Vent Opening Reference | If fitted, 80 mm diameter |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 700× 350 mm/carton according to carcass split | |
| Reference Packaged Gross Weight | 100 kg/set in 3 cartons | |
| Reference Packaging Volume | 0.65 m³/set |
Recommended spaces / users / usage modes
| Open office workstation zone | Placed under or beside desks for shared document and supply storage | |
|---|---|---|
| Private executive office | Positioned beside desk for printer placement and locked confidential file storage | |
| Small office meeting room | Used for storing meeting supplies, materials, and presentation equipment | |
| Home office workspace | Functions as printer stand and lockable storage for personal work documents | |
| Reception back office | Stores visitor supplies, forms, and office consumables behind locked access | |
| Coworking space storage zone | Shared locked storage for individual member supplies and documents |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable to structural stability and anti-tip performance | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture stability and strength requirements, applicable to shelf and surface load testing | |
| EN 13722:2004 | Furniture caster performance requirements for mobile office seating and storage | |
| EN 312:2010 | Particleboard performance requirements for furniture-grade panel construction |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.9 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to panel construction and finish performance | |
|---|---|---|
| GB/T 4893.8-2013 | Surface wear resistance test for furniture surfaces, applicable to laminate top and door finishes | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ for indoor office use | |
| GB/T 10357.5-2011 | Mechanical performance test for storage furniture, applicable to shelf and structural load testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to panel construction and finish performance; 2. GB/T 4893.8-2013: Surface wear resistance test for furniture surfaces, applicable to laminate top and door finishes; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, E1 grade ≤0.124mg/m³ for indoor office use; 4. GB/T 10357.5-2011: Mechanical performance test for storage furniture, applicable to shelf and structural load testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
