Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1683 x 473 x 860 mm | |
|---|---|---|
| top surface thickness | 25 mm | |
| door panel thickness | 18 mm | |
| shelf board thickness | 15 mm | |
| open compartment internal width | 300 mm | |
| closed door compartment internal width | 300 mm | |
| interior shelf clearance height | 240 mm | |
| unit floor clearance height | 20 mm | |
| leveling foot diameter | 30 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| product net weight | 79 kg | |
|---|---|---|
| top surface static load capacity | 50 kg | |
| total storage capacity | 380 L | |
| recommended user count | 10 | |
| door hinge cycle rating | 50000 cycles | |
| surface scratch resistance | 300 cycles | |
| lock service life | 10000 cycles | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| main structural panels | 18mm thick E1 grade MDF substrate | |
|---|---|---|
| exterior finish | Smooth matte off-white thermofused laminate | |
| interior compartment finish | Warm brown wood-grain laminate | |
| door hinges | Cold-rolled steel soft-close concealed hinges | |
| door locks | Zinc alloy keyed-alike cam locks | |
| adjustable shelf supports | Nickel-plated steel shelf pegs | |
| base leveling feet | Reinforced nylon with non-slip rubber base | |
| top surface edge banding | 2mm thick matching PVC edge banding | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| locking storage | 3 keyed-alike lockable closed doors for secure confidential document storage | |
|---|---|---|
| adjustable shelving | 2 open bays with 3 height-adjustable shelves each, 64mm hole spacing for flexible storage | |
| leveling adjustment | 4 corner adjustable feet with 10mm vertical adjustment to compensate for uneven floors | |
| display top surface | Flat sealed top surface for decorative items, office supplies or small plants | |
| door operation | Flush-mounted doors open 110 degrees outward with soft-close damping to prevent slamming | |
| wall anti-tip anchoring | Included wall anchor bracket to prevent tipping when fully loaded | |
| cable management | Rear knock-out panel openings for optional device charging cord routing | |
| lock core diameter | 16 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| open plan office areas | Placed against partition walls for shared team document and supply storage | |
|---|---|---|
| private executive offices | Positioned behind or beside desks for mixed secure storage and open display | |
| reception and waiting areas | Used to hold brochures, reception supplies and decorative displays | |
| small meeting rooms | Placed along walls for meeting material storage and top surface refreshment setup | |
| recommended configuration | Pair with ergonomic office chairs and matching height-adjustable desks for cohesive office fit-out |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety requirements for domestic and kitchen storage furniture, applicable for structural stability | |
|---|---|---|
| EN 312:2010 | Particleboard specifications, applicable for structural panel performance | |
| EN 12521:2015 | Strength, durability and safety requirements for non-domestic storage furniture |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2020 | Performance standard for storage furniture, applicable for load and cycle testing |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel structural integrity | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement | |
| GB/T 4893.8-2013 | Surface wear resistance test for furniture finishes, applicable for laminate top durability |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel structural integrity; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade ≤0.124mg/m³ requirement; 3. GB/T 4893.8-2013: Surface wear resistance test for furniture finishes, applicable for laminate top durability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
