Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1800 x 400 x 850 mm | |
|---|---|---|
| top display ledge height | 70 mm | |
| upper left open cubby dimensions | 480 x 330 x 350 mm | |
| right side two-tier open shelf dimensions | 420 x 330 x 780 mm | |
| lower closed cabinet door height | 430 mm | |
| shelf panel thickness | 36 mm | |
| door panel thickness | 18 mm | |
| frame edge thickness | 3 mm | |
| ribbed trim band height | 50 mm | |
| internal shelf depth behind doors | 370 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| net product weight | 50 kg | |
|---|---|---|
| top surface static load capacity | 73 kg | |
| surface scratch resistance | 2000 cycles | |
| finish stain resistance | Level 4 | |
| recommended warranty period | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| main cabinet carcass | Melamine-faced chipboard (MFC) | |
|---|---|---|
| lower door panels | Textured brown melamine with diagonal embossed pattern | |
| frame and trim components | Dark grey powder-coated steel-look engineered wood trim | |
| open shelf surfaces | Dark grey matte melamine laminate | |
| edge banding | 3mm thick PVC edge trim | |
| internal cabinet shelves | 18mm thick MFC with adjustable mounting holes | |
| door hinges | Soft-close concealed steel hinges | |
| base plinth | Dark grey laminated MFC with leveler feet | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| open upper storage | Three divided cubbies for frequently accessed documents and display items | |
|---|---|---|
| sloped side open shelving | Two-tier curved end shelf for books and decorative display | |
| closed lower storage | Four vertical swing doors concealing internal adjustable shelves | |
| adjustable internal shelving | Two position settings per cabinet bay for variable item heights | |
| soft-close door operation | Hinges prevent slamming and reduce office noise | |
| leveler adjustment | 15mm height adjustment per foot to compensate for uneven floors | |
| scratch-resistant top surface | Melamine finish supports printer, decor and office equipment placement | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| executive office placement | Positioned behind or beside executive desks for document and decor storage | |
|---|---|---|
| meeting room use | Installed along meeting room walls for shared supplies and display items | |
| reception area storage | Used behind reception counters for collateral and decorative display | |
| manager office storage | Provides mixed open/closed storage for work documents and personal items | |
| open office side storage | Placed as a room divider with dual-side accessible open display shelves |
EU Market Access Requirements* EN Standards
| EN 14749:2016 | Safety and strength requirements for domestic and office storage furniture | |
|---|---|---|
| EN 12521:2015 | Strength, durability and safety for commercial office furniture | |
| EN 312:2010 | Particleboard specifications for furniture grade panels |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture performance standard for office use | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard for material emissions and durability |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural integrity | |
|---|---|---|
| GB/T 4897.3-2003 | Particleboard for furniture use, applicable for MFC carcass material | |
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, E1 grade required |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural integrity; 2. GB/T 4897.3-2003: Particleboard for furniture use, applicable for MFC carcass material; 3. GB 18580-2017: Formaldehyde emission limits for wood-based panels, E1 grade required; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
