PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	900 × 450 × 1200 mm
Overall cabinet dimensions	900 x 450 x 1200 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Gross cabinet weight	42 kg
Shelf distributed static load	30 kg per shelf
Total cabinet static storage load	90 kg
Top surface distributed load	40 kg
Door hinge load rating	20 kg per door
Leveling adjustment range	10 mm per foot
Recommended binder capacity	45 standard A4 binders
Door swing durability	100000 open/close cycles
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main carcass	Cold-rolled steel sheet with folded corner construction and gray powder-coated finish
Front doors	0.8 mm flat steel panels with white powder-coated surface
Internal shelves	Steel shelves with folded perimeter edges and powder-coated finish
Back panel	0.5 mm steel sheet with formed edge flanges
Hinges	Steel concealed or semi-concealed hinges with zinc-plated or painted finish
Lock and keys	Keyed cylinder lock with steel lock rod or cam mechanism and two keys

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Locking storage	Key-operated lock secures both doors through a three-point or central latching mechanism suitable for offices and staff rooms
Door access	Two side-hinged doors open outward to provide full-width access to the internal shelf bays
Shelf adjustment	Shelves use side-panel slots or shelf supports at 32 mm vertical increments for flexible file and consumables storage
Floor leveling	Four adjustable feet align the cabinet independently on level or slightly uneven floors

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton count	1 flat-packed carton
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office filing and stationery storage	Suitable for administrative offices, copy rooms and supply areas requiring lockable storage with three shelf levels
Staff room or back-of-house storage	Suitable for consumables, documents and personal items where restricted access and wipe-clean metal surfaces are required

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MC-2D-900-450-1200

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MC-2D-900-450-1200

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MC-2D-900-450-1200Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Lockable Two-Door Metal Storage Cabinet is a freestanding steel storage solution with a clean, functional appearance suited to organised workspaces. Its two flat white steel doors contrast with the gray carcass and top, creating a neutral profile that integrates with office, utility, and back-of-house interiors. The side-hinged doors open outward to give full-width access to the interior, where adjustable steel shelves provide three shelf levels for files, stationery, consumables, and personal items. The cabinet is constructed from cold-rolled steel with folded corner construction and a gray powder-coated carcass finish. The doors use 0.8 mm flat steel panels with a white powder-coated surface, while the internal shelves feature folded perimeter edges and a matching powder-coated finish. A formed steel back panel, steel concealed or semi-concealed hinges, and a keyed cylinder lock complete the robust metal construction. The lock secures both doors through a three-point or central latching mechanism and is supplied with two keys, supporting controlled access in shared environments. Flexible storage is provided by shelves that adjust through side-panel slots or shelf supports at 32 mm vertical increments. This allows the interior to be arranged for A4 binders, documents, office supplies, cleaning consumables, or mixed-height items. The cabinet is rated for a shelf distributed static load of 30 kg per shelf, a total cabinet static storage load of 90 kg, and a top surface distributed load of 40 kg. Each door hinge has a 20 kg load rating, and four adjustable feet provide 10 mm of leveling adjustment per foot for stable positioning on level or slightly uneven floors. Typical settings include administrative offices, copy rooms, supply rooms, staff rooms, and back-of-house areas where lockable storage and wipe-clean metal surfaces are beneficial. Its recommended binder capacity is 45 standard A4 binders, making it a practical choice for routine document management and secure day-to-day storage. Overall dimensions are 900 x 450 x 1200 mm, with a gross cabinet weight of 42 kg. Procurement planning should allow space for outward-opening doors and access for shelf adjustment. The stated flat-packed configuration is one carton, while reference logistics also describe split-carcass packaging, so delivery and handling details should be confirmed at order stage. A reference assembly time of 40 minutes per set should be treated as planning guidance, and installation should be checked for stable leveling and correct door latching before use.
