Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 406 x 787 mm | |
|---|---|---|
| Left lower cabinet door height | 517 mm | |
| Middle cubby divider position | 393 mm above interior floor | |
| Cubby interior width per bay | 450 mm | |
| Top surface thickness | 25 mm | |
| Base plinth height | 50 mm | |
| Interior shelf thickness | 18 mm | |
| Side panel thickness | 18 mm | |
| Primary Component Thickness | 40 mm according to load-bearing role | |
| Hardware / Moving-part Clearance | 5 mm operating clearance |
Net weight / load capacity / users / durability
| Top surface static load capacity | 75 kg | |
|---|---|---|
| Product net weight | 52 kg | |
| Laminate surface abrasion resistance | 2000 cycles | |
| Recommended manufacturer warranty | 10 years | |
| Reference Static Load | 150 kg depending on category | |
| Moving-part Durability Reference | Acceptance target 50000 cycles | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years |
Core acceptance fields · Panels / hardware / frame / upholstery
| Core panel construction | 18mm E1-grade engineered wood (MDF/particleboard) | |
|---|---|---|
| Top surface finish | Walnut wood-grain scratch and stain resistant laminate | |
| Drawer front finish | Beige matte laminate panel | |
| Left cabinet door finish | Walnut wood-grain laminate matching cabinet body | |
| Edge banding | 1mm matching PVC edge trim on all exposed panel edges | |
| Fixed middle shelf | 18mm beige laminate engineered wood | |
| Drawer lock hardware | Zinc alloy cam lock with keyed cylinder | |
| Drawer slides | Full-extension ball-bearing steel slides | |
| Divider panels | 18mm laminate engineered wood matching interior finish | |
| Primary Connector Specification | Reference M6-M10 with at least 2 fixing points at major joints | |
| Reference Finish / Color Count | Recommended 6finish options |
Adjustment / rotation / tilt / mobility / storage features
| Left upper drawer operation | Key-locking utility drawer secured by cam lock, full extension access | |
|---|---|---|
| Left lower storage compartment | Enclosed solid-door cabinet for concealed office supply storage | |
| Middle bay storage | Two vertically stacked fixed open cubbies for frequently accessed items | |
| Right storage bay | Full-height open compartment designed for optional locking door installation | |
| Top surface use | Flat continuous work surface for printers, scanners, or office equipment placement | |
| Security feature | Keyed lock secures upper drawer and lower left cabinet compartment | |
| Installation type | Freestanding stationary unit with flush floor base, no casters | |
| Left locking drawer height | 220 mm | |
| Reference Adjustment / Operating Range | 100 mm or 120° where applicable |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Packaging Volume | 0.8 m³/set | |
| Reference Packaged Gross Weight | 120 kg/set |
Recommended spaces / users / usage modes
| Open plan office side storage | Placed alongside workstations to hold supplies, files, and shared office equipment | |
|---|---|---|
| Executive office supplementary storage | Positioned against a wall behind or beside an executive desk for printer and document storage | |
| Small business reception area | Used to store reception supplies, brochures, and office equipment out of visitor sight | |
| Home office workspace storage | Installed in home offices to organize work materials and support printer placement | |
| Printer and copier stand | Flat top supports mid-sized office printers with adjacent open storage for paper and supplies |
EU Market Access Requirements* EN Standards
| EN 14073-2:2004 | Office storage furniture safety requirements, applicable for structural stability and edge safety | |
|---|---|---|
| EN 14073-3:2004 | Office storage furniture strength and durability test methods, applicable for load cycle performance | |
| EN 13722:2004 | Furniture surface resistance to cold liquids, applicable to laminate stain resistance verification |
US and Canada office-furniture standards
| ANSI/BIFMA X5.9-2019 | Storage furniture standard for commercial office use, applicable for load and stability testing | |
|---|---|---|
| ANSI/BIFMA e3-2019 | Furniture sustainability standard, applicable for material emissions and lifecycle criteria |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for panel construction and finish quality | |
|---|---|---|
| GB 18580-2017 | Formaldehyde emission limits for wood-based panels, required for indoor office furniture air quality | |
| GB/T 4893.8-2013 | Surface abrasion resistance test for furniture surfaces, applicable to laminate finish durability | |
| GB/T 10357.5-2013 | Furniture mechanical performance test for storage units, applicable for shelf and top load ratings |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for panel construction and finish quality; 2. GB 18580-2017: Formaldehyde emission limits for wood-based panels, required for indoor office furniture air quality; 3. GB/T 4893.8-2013: Surface abrasion resistance test for furniture surfaces, applicable to laminate finish durability; 4. GB/T 10357.5-2013: Furniture mechanical performance test for storage units, applicable for shelf and top load ratings; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
