PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1200 × 450 × 1000 mm
Overall cabinet size	1200 x 450 x 1000 mm
Carcass Panel Thickness	25 mm
Back Panel Thickness	9 mm
Door / Drawer Front Thickness	22 mm
Shelf Thickness	25 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	42 kg
Uniform shelf load	40 kg per shelf
Total static storage load	120 kg
Top-surface static load	60 kg
Recommended internal file-box capacity	12 standard A4 file boxes
Leveling adjustment	10 mm total vertical compensation
Door lock positions	2 key positions: locked and unlocked
Service life reference	100,000 door-sliding cycles
Shelf Distributed Load	30 kg/shelf
Drawer Slide Load / Life	45 kg/pair; 50000 cycles

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Carcass panels	Grey powder-coated folded steel case with welded or concealed corner construction
Front doors	Three white steel sliding panels with flush face finish and narrow vertical gaps
Door track	Top and bottom steel or aluminium running tracks with integrated anti-jump guide
Lock set	Key-operated cam lock with black housing and two keys assumed
Internal shelves	Adjustable cold-rolled steel shelves supported by metal shelf pins or bracket strips
Leveling feet	Four black polymer or nylon feet with steel threaded stems

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Sliding door operation	Three panels run horizontally on top and bottom tracks, reducing aisle clearance demand compared with hinged doors
Centralized locking	Key-operated cam lock secures the sliding-door run for controlled office storage
Adjustable shelving	Two shelves reposition vertically to store A4 files, binders or general office supplies
Floor leveling	Four independently rotated feet correct uneven floors and keep the door tracks aligned

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Carton dimensions	1260 x 500 x 180 mm
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Package Dimensions	2100× 700× 350 mm/carton according to carcass split
Reference Packaged Gross Weight	100 kg/set in 3 cartons
Reference Packaging Volume	0.65 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Office storage and filing	Suitable for open offices, administrative areas and back offices requiring locked A4 files, supplies and equipment storage
Reception or pantry support	Usable behind a reception counter or in a pantry zone for locked consumables with a restrained top display area

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · MC-3D-1200-LOW-LIP

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · MC-3D-1200-LOW-LIP

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · MC-3D-1200-LOW-LIPOpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Three-Door Locked Metal Storage Cabinet with Raised Back Lip offers a practical storage solution for offices and support areas requiring secure filing and general storage. Model MC-3D-1200-LOW-LIP is unbranded and presents a grey steel carcass with three white steel sliding doors. The flush front panels and narrow vertical gaps create a clean, orderly appearance, while the raised back lip provides a restrained top surface and helps define the rear edge of displayed or temporarily placed items. Measuring 1200 mm wide, 450 mm deep, and 1000 mm high, the cabinet has a compact, low-height form suited to working environments. Its grey carcass is made from powder-coated folded steel with welded or concealed corner construction. The carcass panels and internal shelves are 25 mm thick, the back panel is 9 mm thick, and each sliding door panel is 22 mm thick. Three white steel panels move horizontally on top and bottom steel or aluminium running tracks, each fitted with an integrated anti-jump guide. A recessed lock handle contributes to the smooth front profile. The key-operated cam lock has a black housing and secures the sliding-door run, with locked and unlocked positions; two keys are assumed. Inside, two adjustable cold-rolled steel shelves are supported by metal shelf pins or bracket strips, allowing the interior to be arranged for A4 files, binders, office supplies, or equipment. The cabinet is rated for a uniform shelf load of 40 kg per shelf, a total static storage load of 120 kg, and a top-surface static load of 60 kg. Its recommended internal filing capacity is 12 standard A4 file boxes. The cabinet weighs 42 kg net and rests on four black polymer or nylon leveling feet with steel threaded stems. Each foot rotates independently, providing 10 mm of total vertical compensation to correct uneven floors and maintain door-track alignment. Sliding doors make the cabinet particularly suitable where aisle clearance is limited, because the panels do not swing outward. It works well in open offices, administrative areas, and back offices for controlled file storage. It can also be placed behind a reception counter or in a pantry area to store consumables securely while maintaining a tidy top surface. Procurement planning should account for site access, floor protection, and assembly resources. Reference logistics indicate a 40-minute assembly time per set. Packing details vary across the supplied information, including a two-carton configuration and a split-carcass configuration of three cartons with 100 kg packaged gross weight and 0.65 cubic metre packaging volume, so shipment-specific packing should be confirmed before ordering.
